Citation: Qinyao Jiang, Binhao Wang, Zerui Yan, Sicheng Fan, Dafu Tang, Biwei Xiao, Qiulong Wei. Unraveling the pseudocapacitive sodium-ion storage mechanism of birnessite in organic electrolytes[J]. Chinese Chemical Letters, ;2025, 36(11): 110416. doi: 10.1016/j.cclet.2024.110416 shu

Unraveling the pseudocapacitive sodium-ion storage mechanism of birnessite in organic electrolytes

Qinyao Jiang ^a ,
Binhao Wang ^a ,
Zerui Yan ^a ,
Sicheng Fan ^a ,
Dafu Tang ^a ,
Biwei Xiao ^{b, *,} ,
Qiulong Wei ^{a, *,}

a.
Department of Materials Science and Engineering, Fujian Key Laboratory of Surface and Interface Engineering for High Performance Materials, College of Materials, Xiamen University, Xiamen 361005, China
b.
GRINM (Guangdong) Research Institute for Advanced Materials and Technology, Foshan 528051, China

xiaobiwei@grinm.com

qlwei@xmu.edu.cn

Received Date: 25 July 2024
Revised Date: 21 August 2024
Accepted Date: 5 September 2024
Available Online: 6 September 2024

Figures(5)

Earth-abundant, layered birnessite is promising cathode for electrochemical capacitors due to the presence of confined nanofluids in interlayers for rapid ion storage. Previous work has demonstrated the capacitive co-intercalation of water and K⁺ ions into birnessite in aqueous electrolytes, but in-depth quantitative investigations of the interactions between confined water and an external organic electrolyte are still lacking. In this work, we reveal the intercalation pseudocapacitance of hydrated birnessite (Na_0.4MnO₂·0.53H₂O) in sodium-based organic electrolytes via operando electrochemical quartz crystal microbalance (EQCM), and ex situ X-ray diffraction and Raman spectroscopy. The Na⁺ ions are completely desolvated at the Na_0.4MnO₂·0.53H₂O-organic electrolyte interfaces and intercalate into the interlayers, while the confined water does not co-extract. The net Na⁺ intercalation is a pseudocapacitive behavior without phase changes, displaying a high capacitive contribution of 85.6% at 1.0 mV/s. Additionally, EQCM results indicate the contributions of cation-dominated electric double layer (EDL) adsorption to the total charge storage. By replacing different solvents and anions in sodium-based organic electrolytes, we verify that Na⁺ pseudocapacitive intercalation dominates the charge storage properties.
- Pseudocapacitance,
- Sodium-ion storage,
- Interlayer confinement,
- Birnessite,
- EQCM
