Citation: Siqi Sun, Cheng Zhao, Zhaohuan Zhang, Ding Wang, Xinru Yin, Jingting Han, Jinlei Wei, Yong Zhao, Yongheng Zhu. Highly selective QCM sensor based on functionalized hierarchical hollow TiO₂ nanospheres for detecting ppb-level 3-hydroxy-2-butanone biomarker at room temperature[J]. Chinese Chemical Letters, ;2025, 36(5): 109939. doi: 10.1016/j.cclet.2024.109939 shu

Highly selective QCM sensor based on functionalized hierarchical hollow TiO₂ nanospheres for detecting ppb-level 3-hydroxy-2-butanone biomarker at room temperature

Siqi Sun ^{a, 1} ,
Cheng Zhao ^{a, b, 1} ,
Zhaohuan Zhang ^a ,
Ding Wang ^c ,
Xinru Yin ^a ,
Jingting Han ^a ,
Jinlei Wei ^a ,
Yong Zhao ^{a, *,} ,
Yongheng Zhu ^{a, *,}

a.
College of Food Science and Technology, Laboratory of Quality & Safety Risk Assessment for Aquatic Products on Storage and Preservation (Shanghai), Ministry of Agriculture and Shanghai Engineering Research Center of Aquatic Product Processing & Preservation, Shanghai Ocean University, Shanghai 201306, China
b.
Henan Railway Food Safety Management Engineering Technology Research Center, Zhengzhou Railway Vocational & Technical College, Zhengzhou 451460, China
c.
School of Materials Science and Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China

yzhao@shou.edu.cn

yh-zhu@shou.edu.cn

Received Date: 30 January 2024
Revised Date: 11 March 2024
Accepted Date: 28 April 2024
Available Online: 29 April 2024

Figures(5)

Listeria monocytogenes (LM) is a dangerous foodborne pathogen for humans. One emerging and validated method of indirectly assessing LM in food is detecting 3-hydroxy-2-butanone (3H2B) gas. In this study, the synthesis of 3-(2-aminoethylamino) propyltrimethoxysilane (AAPTMS) functionalized hierarchical hollow TiO₂ nanospheres was achieved via precise controlling of solvothermal reaction temperature and post-grafting route. The sensors based on as-prepared materials exhibited excellent sensitivity (480 Hz@50 ppm), low detection limit (100 ppb), and outstanding selectivity. Moreover, the evaluation of LM with high sensitivity and specificity was achieved using the sensors. Such stable three-dimensional spheres, whose distinctive hierarchical and hollow nanostructure simultaneously improved both sensitivity and response/recovery speed dramatically, were spontaneously assembled by nanosheets. Meanwhile, the moderate loadings of AAPTMS significantly improved the selectivity of sensors. Then, the gas-sensing mechanism was explored by utilizing thermodynamic investigation, Gaussian 16 software, and in situ diffuse reflectance infrared transform spectroscopy, illustrating the weak chemisorption between the -NH- group and 3H2B molecules. These portable sensors are promising for real-time assessment of LM at room temperature, which will make a magnificent contribution to food safety.
- Hierarchical hollow TiO₂ nanospheres,
- AAPTMS functionalization,
- Gas sensor,
- 3-Hydroxy-2-butanone detection,
- Sensing mechanism
