Enhanced oxygen reduction reaction performance of Co@N–C derived from metal-organic frameworks ZIF-67 via a continuous microchannel reactor

Chenxu Wang ^a ,
Huifang Yuan ^a ,
Feng Yu ^{a, c, *,} ,
Jie Zhang ^a ,
Yangyang Li ^a ,
Wentao Bao ^a ,
Zhimou Wang ^a ,
Ke Lu ^a ,
Jie Yu ^a ,
Ge Bai ^a ,
Gang Wang ^a ,
Banghua Peng ^{a, *,} ,
Lili Zhang ^{b, *,}

a.
Key Laboratory for Green Processing of Chemical Engineering of Xinjiang Bingtuan, School of Chemistry and Chemical Engineering, Shihezi University, Shihezi 832003, China
b.
Institute of Chemical and Engineering Sciences, Agency for Science, Technology and Research, Jurong Island 627833, Singapore
c.
Bingtuan Industrial Technology Research Institute, Shihezi University, Shihezi 832003, China

yufeng05@mail.ipc.ac.cn

banghuapeng@163.com

zhang.lili@ices.a.star.edu.sg

Received Date: 7 December 2021
Revised Date: 4 January 2022
Accepted Date: 9 January 2022
Available Online: 15 January 2022

Figures(4)

Traditional methods of preparing metal-organic frameworks (MOFs) compounds have the disadvantages such as poor dispersion, inefficient and discontinuous process. In this work, microchannel reactor is used to prepare MOFs-derived zeolite-imidazole material via flash nanoprecipitation to form ZIF-67 + PEI(FNP), which reduces the MOF synthesis time down to millisecond time interval while keeping the synthesized ZIF-67 + PEI(FNP) highly dispersed. The Co@N–C(FNP)catalyst obtained by flash nanoprecipitation and carbonization has a higher Co content and thus more active sites for oxygen reduction reaction than the Co@N–C(DM) catalyst prepared by direct mixing method. Electrochemical tests show that the Co@N–C(FNP) catalyst prepared by this method has excellent oxygen reduction performance, good methanol resistance and high stability. The onset potential and half-wave potential of Co@N–C(FNP) are 0.92 V_RHE and 0.83 V_RHE, respectively, which are higher than that of Co@N–C(DM) (E_onset = 0.90 V_RHE and E_1/2 = 0.83 V_RHE). Moreover, the Zn-air battery assembled with Co@N–C(FNP) as the cathode catalyst has high open circuit voltage, high power density and large specific capacity. The performance of these batteries has been comparable to that of Pt/C assembled batteries. Density functional theory (DFT) calculations confirm that the Co (220) crystal plane present in Co@N–C(FNP) have stronger adsorption energy than that of Co (111) crystal plane in Co@N–C(DM), leading to better electrocatalytic performance of the former.
