Citation: Hou Huanhuan, Duan Liang, Zhou Beihai, Tian Yuan, Wei Jian, Qian Feng. The performance and degradation mechanism of sulfamethazine from wastewater using IFAS-MBR[J]. Chinese Chemical Letters, ;2020, 31(2): 543-546. doi: 10.1016/j.cclet.2019.08.031 shu

The performance and degradation mechanism of sulfamethazine from wastewater using IFAS-MBR

Hou Huanhuan ^a,b,c ,
Duan Liang ^b,c,*, ,
Zhou Beihai ^a,*, ,
Tian Yuan ^b ,
Wei Jian ^b ,
Qian Feng ^b

a.
Beijing Key Laboratory of Resource-oriented Treatment of Industrial Pollutants, School of Energy and Environmental Engineering, University of Science and Technology Beijing, Beijing 100083, China
b.
State Key Laboratory of Environmental Criteria and Risk Assessment, Chinese Research Academy of Environmental Sciences, Beijing 100012, China
c.
State Environmental Protection Key Laboratory of Estuarine and Coastal Environment, Chinese Research Academy of Environmental Sciences, Beijing 100012, China

duanliang@craes.org.cn

zhoubeihai@sina.com

Received Date: 1 July 2019
Revised Date: 15 August 2019
Accepted Date: 20 August 2019
Available Online: 21 August 2019

Figures(4)

Sulfamethazine (SMZ) is an important sulfonamide antibiotic. Although the concentration in the environment is small, it is harmful. The drug residues can be transferred, transformed or accumulated, affecting the growth of animals and plants. In this study, the integrated fixed-film activated sludge membrane bioreactor (IFAS-MBR) were constructed to investigate the performance and degradation mechanism of SMZ. The addition of SMZ had a significant impact on the removal of the chemical oxygen demand (COD) and ammonia nitrogen (NH₄⁺-N). The optimal operating conditions were hydraulic retention time (HRT) at 10 h and solid retention time (SRT) at 80 d, respectively. On this basis, the effects of different SMZ concentrations on nutrient removal, degradation, and sludge characteristics were compared. The removal efficiency of SMZ increased with the increase of SMZ concentration. The maximum removal rate was as high as 87%. The SMZ dosage also had an obvious effect on sludge characteristics. As the SMZ concentration increased, the extracellular polymer substances (EPS) concentration and the membrane resistance both decreased, which were beneficial for the reduction of membrane fouling. Finally, seven kinds of SMZ biodegradation intermediates were identified, and the possible degradation pathways were speculated. The microbial community results showed that the microbial diversity and richness in the reactor decreased after adding SMZ to the influent. The relative abundance of Bacteroidetes, Actinobacteria, Saccharibacteria and Nitrospirae increased at the phylum level. Sphingobacteria and Betaproteobacteria became dominant species at the class level. The relative abundance of norankp-Saccharibacteria and Nitrospirae increased significantly, and norank-p-Saccharibacteria may be the dominant bacteria for SMZ degradation.
- IFAS-MBR,
- Sulfamethazine,
- Biodegradation,
- Membrane fouling,
- Microbial characteristics
1. [1]
  G. Mannina, M. Capodici, A. Cosenza, et al., J. Environ. Manage. 187(2017) 96-102. doi: 10.1016/j.jenvman.2016.11.025
2. [2]
  J.C. Leyva-Diaz, J. Martín-Pascual, M.M. Munío, et al., Ecol. Eng. 70(2014) 227-234. doi: 10.1016/j.ecoleng.2014.05.017
3. [3]
  D. Nematollahi, S.S.H. Davarani, P. Mirahmadpour, et al., Chin. Chem. Lett. 25(2014) 593-595. doi: 10.1016/j.cclet.2014.01.005
4. [4]
  S.P. Rong, Y.B. Sun, Z.H. Zhao, Chin. Chem. Lett. 25(2014) 187-192. doi: 10.1016/j.cclet.2013.11.003
5. [5]
  S.G. Michael, I. Michael-Kordatou, V.G. Beretsou, et al., Appl. Catal. B 244(2019) 871-880. doi: 10.1016/j.apcatb.2018.12.030
6. [6]
  Q. Zhou, M.C. Zhang, C.D. Shuang, et al., Chin. Chem. Lett. 23(2012) 745-748. doi: 10.1016/j.cclet.2012.01.039
7. [7]
  I.C. Iakovides, I. Michael-Kordatou, N.F.F. Moreira, et al., Water Res. 159(2019) 333-347. doi: 10.1016/j.watres.2019.05.025
8. [8]
  J. Chen, Y.S. Liu, J.N. Zhang, et al., Bioresour. Technol. 238(2017) 70-77. doi: 10.1016/j.biortech.2017.04.023
9. [9]
  B.J. Shi, Y. Wang, Y.K. Geng, et al., Chemosphere 193(2018) 840-846. doi: 10.1016/j.chemosphere.2017.11.051
10. [10]
  W. Zhao, Q. Sui, X. Mei, et al., Sci. Total Environ. 633(2018) 668-676. doi: 10.1016/j.scitotenv.2018.03.207
11. [11]
  L. Duan, Z. Tian, Y. Song, et al., Biofouling 31(2015) 181-191. doi: 10.1080/08927014.2015.1020303
12. [12]
  L. Song, H. Zhang, T. Cai, et al., Chin. Chem. Lett. 30(2019) 863-866. doi: 10.1016/j.cclet.2018.10.040
13. [13]
  C.S. Wu, Z.X. Jia, B.M. Ning, et al., Chin. Chem. Lett. 23(2012) 1185-1188. doi: 10.1016/j.cclet.2012.09.001
14. [14]
  W.W. Ben, Z.M. Qiang, X.W. Yin, et al., J. Environ. Sci. 26(2014) 1623-1629. doi: 10.1016/j.jes.2014.06.002
15. [15]
  J. Liu, C.C. Deng, Y.X. Deng, et al., Water Res. 145(2018) 312-320. doi: 10.1016/j.watres.2018.08.039
16. [16]
  B. Frolund, R. Palmgren, K. Keiding, et al., Water Res. 30(1996) 1749-1758. doi: 10.1016/0043-1354(95)00323-1
17. [17]
  H. Choi, K. Zhang, D. Dionysios, Sep. Purif. Technol. 45(2015) 68-78. doi: 10.1016/j.seppur.2005.02.010
18. [18]
  H.F. Schröder, J.L. Tambosi, R.F. Sena, et al., Water Sci. Technol. 65(2012) 833-839. doi: 10.2166/wst.2012.828
19. [19]
  M.J. Garcia Galan, M.S. Diaz-Cruz, D. Barcelo, Anal. Bioanal. Chem. 404(2012) 1505-1515. doi: 10.1007/s00216-012-6239-5
20. [20]
  J. Park, N. Yamashita, H. Tanaka, Chemosphere 197(2018) 467-508. doi: 10.1016/j.chemosphere.2018.01.063
21. [21]
  T. Zhang, M. Shao, L. Ye, ISME J. 6(2012) 1137-1147. doi: 10.1038/ismej.2011.188
22. [22]
  C. Qi, J. Wang, Y. Lin, Bioresour. Technol. 211(2016) 654-663. doi: 10.1016/j.biortech.2016.03.143
23. [23]
  D.W. Gao, T. Zhang, C.Y.Y. Tang, et al., J. Member. Sci. 364(2010) 331-338. doi: 10.1016/j.memsci.2010.08.031
24. [24]
  D. Zhang, J. Li, P. Guo, et al., Bioresour. Technol. 102(2011) 4703-4711. doi: 10.1016/j.biortech.2011.01.044
25. [25]
  C. Chen, Y. Fu, D. Gao, Bioresour. Technol. 197(2015) 185-192. doi: 10.1016/j.biortech.2015.08.092
26. [26]
  N. Remmas, P. Melidis, I. Zerva, et al., Bioresour. Technol. 238(2017) 48-56. doi: 10.1016/j.biortech.2017.04.019
