Recent advances in metal-organic frameworks for lithium metal anode protection

Du Ying ,
Gao Xing ,
Li Siwu ,
Wang Lu ^*, ,
Wang Bo ^*,

Beijing Key Laboratory of Photoelectronic/Electrophotonic Conversion Materials, Key Laboratory of Cluster Science, Ministry of Education, School of Chemistry and Chemical Engineering, Beijing Institute of Technology, Beijing 100081, China

luwang@bit.edu.cn

bowang@bit.edu.cn

Received Date: 18 April 2019
Revised Date: 1 June 2019
Accepted Date: 6 June 2019
Available Online: 6 June 2019

Figures(8)

The lithium metal battery has been considered as a promising candidate for next generation batteries. However, safety concerns caused by uncontrollable lithium dendrite growth on lithium anode are severely hampering the commercial application. Metal-organic frameworks (MOFs) become one of the most attractive materials due to the high porosity, structural designability and tunability. With unique open channels and pores as well as functional components in MOFs, the transportation and deposition of lithium ions can be regulated, which leads to enhanced electrochemical properties. Various strategies for lithium metal protection are proposed in recent works on applications of MOFs in lithium metal batteries. In this review, we highlight latest key approaches in this field and discuss the prospects for MOFs in advanced Li anodes.
