Citation: Zhao Bintao, Lu Xi, Wang Qian, Yang Jingfa, Zhao Jiang, Zhou Henghui. Enhancing the ionic conductivity in a composite polymer electrolyte with ceramic nanoparticles anchored to charged polymer brushes[J]. Chinese Chemical Letters, ;2020, 31(3): 831-835. doi: 10.1016/j.cclet.2019.06.009 shu

Enhancing the ionic conductivity in a composite polymer electrolyte with ceramic nanoparticles anchored to charged polymer brushes

Zhao Bintao ^a,b ,
Lu Xi ^b ,
Wang Qian ^a ,
Yang Jingfa ^c,d ,
Zhao Jiang ^c,d,**, ,
Zhou Henghui ^a,*,

a.
College of Chemistry and Molecular Engineering, Peking University, Beijing 100871, China
b.
Pulead Technology Industry Co. Ltd., Beijing 102200, China
c.
Institute of Chemistry, Chinese Academy of Sciences, Beijing 100190, China
d.
University of Chinese Academy of Sciences, Beijing 100049, China

jzhao@iccas.ac.cn

hhzhou@pku.edu.edu

Received Date: 22 March 2019
Revised Date: 29 April 2019
Accepted Date: 5 June 2019
Available Online: 6 June 2019

Figures(5)

Polymer electrolytes are essential for next-generation lithium batteries because of their excellent safety record. However, low ionic conductivity is the main obstacle restricting their commercial application. Composites with nanoparticles are a promising route to overcome this obstacle. In this work, lithium polystyrene sulfonate brushes (LiPSS) is anchored to silicon dioxide nanoparticles with chemical bonding using atom transfer radial polymerization (SI-ATRP). The composite polymer electrolytes are made by mixing vinylene carbonate and nanoparticles via a facile in situ polymerization process. The ionic conductivity of composite polymer electrolytes is improved to 7.2 ×10^-4 S/cm at room temperature, which is attributed to the low degree of crystallinity of polymer electrolyte and the fast ion transport on the surfaces of polymer brush layers that act as a conductive network. The composite polymer electrolytes show a wide electrochemical window of approximately 4.5 V vs. Li⁺/Li and excellent cycling performance retention of approximately 95% after 100 cycles at ambient temperature. The results also prove that surface groups of ceramic nanoparticles are an important way to increase the electrochemical properties of composite polymer electrolytes.
