Citation: Zhou Peng, Lv Pei, Yu Lu, Liu Sanling, Zhang Longhua, Tian Changlin. Fluorescence lifetime based distance measurement illustrates conformation changes of PYL10-CL2 upon ABA binding in solution state[J]. Chinese Chemical Letters, ;2019, 30(5): 1067-1070. doi: 10.1016/j.cclet.2019.01.020 shu

Fluorescence lifetime based distance measurement illustrates conformation changes of PYL10-CL2 upon ABA binding in solution state

High Magnetic Field Laboratory, Chinese Academy of Sciences and School of Life Sciences, University of Science and Technology of China, Hefei 230027, China

zlhustc@ustc.edu.cn

cltian@ustc.edu.cn

Received Date: 22 December 2018
Revised Date: 18 January 2019
Accepted Date: 22 January 2019
Available Online: 22 May 2019

Figures(3)

Förster resonance energy transfer (FRET) is a widely used distance measurement method to illustrate protein conformational dynamics. The FRET method relies on the distance between donor and acceptor, as well as the labelling efficiency, the size and the properties of the fluorophores. Here, we labelled a pair of small fluorophores and calculated the energy transferred efficiency through fluorescence lifetime analysis, which can provide more reliable distance measurement than intensity attenuation. The donor fluorophore, 7-hydroxycoumarin-4-yl-ethylglycine (HC), was genetically incorporated into specific sites of PYL10, obtaining complete labelling efficiency. The acceptor fluorophore, Alexa488, was labelled through the disulfide bond, whose labelling efficiency was estimated through both absorption peaks and lifetime populations. Fluorescence lifetime and anisotropy analysis showed ABA-induced local conformation changes and dynamics of several HC incorporation sites of PYL10. The lifetime-based FRET distance measurement illustrated the conformation changes of PYL10 with or without ABA application, which is consistent with the previously reported crystal structures.
- Fluorescence lifetime,
- Anisotropy,
- Unnatural amino acid,
- PYL10,
- Distance measurement
1. [1]
  R.M. Clegg, Curr. Opin. Biotechnol. 6(1995) 103-110. doi: 10.1016/0958-1669(95)80016-6
2. [2]
  V.E. Isaac, L. Patel, T. Curran, C. Abate-Shen, Biochemistry 34(1995) 15276-15281. doi: 10.1021/bi00046a036
3. [3]
  L. Ma, F. Yang, J. Zheng, J. Mol. Struct. 1077(2014) 87-100. doi: 10.1016/j.molstruc.2013.12.071
4. [4]
  E.A. Jares-Erijman, T.M. Jovin, Nat. Biotechnol. 21(2003) 1387-1395. doi: 10.1038/nbt896
5. [5]
  A. Margineanu, J.J. Chan, D.J. Kelly, et al., Sci. Rep. 6(2016) 28186. doi: 10.1038/srep28186
6. [6]
  H.S. Chung, J.M. Louis, I.V. Gopich, J. Phys. Chem. B 120(2016) 680-699. doi: 10.1021/acs.jpcb.5b11351
7. [7]
  H.J. Carlson, R.E. Campbell, Curr. Opin. Biotechnol. 20(2009) 19-27. doi: 10.1016/j.copbio.2009.01.003
8. [8]
  S.J. Peng, R.R. Sun, W.J. Wang, C.L. Chen, Chin. Chem. Lett. 29(2018) 1503-1508. doi: 10.1016/j.cclet.2017.12.006
9. [9]
  C. Albrecht, R. Joseph, Lakowicz, Anal. Bioanal. Chem. 390(2008) 1223-1224. doi: 10.1007/s00216-007-1822-x
10. [10]
  M.G. Zhang, M. Wen, Y. Xiong, L.H. Zhang, C.L. Tian, Chin. Chem. Lett. 29(2018) 1509-1512. doi: 10.1016/j.cclet.2018.04.026
11. [11]
  T. Koopmans, M. van Haren, L.Q. van Ufford, J.M. Beekman, N.I. Martin, Bioorg. Med. Chem. 21(2013) 553-559. doi: 10.1016/j.bmc.2012.10.055
12. [12]
  M. Braun, T. Dittrich, Beilstein J. Org. Chem. 6(2010) 69.
13. [13]
  W.J. Qin, C.C. Xu, Y.F. Zhao, et al., Chin. Chem. Lett. 29(2018) 1451-1455. doi: 10.1016/j.cclet.2018.04.007
14. [14]
  T.S. Young, I. Ahmad, J.A. Yin, P.G. Schultz, J. Mol. Biol. 395(2010) 361-374. doi: 10.1016/j.jmb.2009.10.030
15. [15]
  S.M. Wang, Y.A. Zhang, L.H. Zhang, M. Zhang, C.L. Tian, Chin. Chem. Lett. 29(2018) 1513-1516. doi: 10.1016/j.cclet.2018.08.002
16. [16]
  S.L. Liu, P. Lv, D. Li, et al., Chem. Commun. (Camb.) 51(2015) 15971-15974. doi: 10.1039/C5CC06124E
17. [17]
  D. Li, Y.A. Zhang, Y. He, et al., Protein Cell 9(2018) 592. doi: 10.1007/s13238-017-0389-3
18. [18]
  W.H. Cheng, A. Endo, L. Zhou, et al., Plant Cell 14(2002) 2723-2743. doi: 10.1105/tpc.006494
19. [19]
  A. Christmann, D. Moes, A. Himmelbach, et al., Plant Biol. (Stuttg.) 8(2006) 314-325. doi: 10.1055/s-2006-924120
20. [20]
  Y. Ma, I. Szostkiewicz, A. Korte, et al., Science 324(2009) 1064-1068.
21. [21]
  S.Y. Park, P. Fung, N. Nishimura, et al., Science 324(2009) 1068-1071.
22. [22]
  D. Sun, H. Wang, M. Wu, et al., Biochem. Biophys. Res. Commun. 418(2012) 122-127. doi: 10.1016/j.bbrc.2011.12.145
23. [23]
  Q. Hao, P. Yin, W. Li, et al., Mol. Cell 42(2011) 662-672. doi: 10.1016/j.molcel.2011.05.011
24. [24]
  M. Ameloot, M. vandeVen, A.U. Acuna, B. Valeur, Pure Appl. Chem. 85(2013) 589-608. doi: 10.1351/PAC-REP-11-11-12
