Citation: Kan Junjie, Wang Shuguang, Wang Zhongwu, Guo Shujing, Wang Wenchong, Li Liqiang. Fabrication of flexible thin organic transistors by trace water assisted transfer method[J]. Chinese Chemical Letters, ;2018, 29(11): 1681-1684. doi: 10.1016/j.cclet.2018.07.015 shu

Fabrication of flexible thin organic transistors by trace water assisted transfer method

a.
Institute of Nanochemistry and Nanobiology, School of Environmental and Chemical Engineering, Shanghai University, Shanghai 200444, China
b.
Advanced Nano-materials Division, Key Laboratory of Nano-Devices and Applications, Suzhou Institute of Nano-Tech and Nano-Bionics, Chinese Academy of Sciences, Suzhou 215123, China

Corresponding author: Wang Wenchong, wenchong@shu.edu.cn Li Liqiang, lqli2014@sinano.ac.cn; llq@iccas.ac.cn
Received Date: 25 May 2018
Revised Date: 3 July 2018
Accepted Date: 20 July 2018
Available Online: 20 November 2018

Figures(4)

The development of fabrication method for flexible thin organic electronic device is highly important for the flexible and wearable products. Herein, we develop a facile peel-off method to transfer organic thin film to various substrates. In this strategy, polyacrylonitrile (PAN) film can be easily peeled off with trace water and further transferred to various substrates. Using PAN as supporting and dielectric layers, high performance flexible organic transistors are fabricated. Remarkably, the method uses only micro volume water as an assist to peel off PAN film, which reduces the risk of contamination by solvent and greatly contributes to the performance maintenance.
- Transfer,
- Flexible,
- Thin film organic transistor,
- Peel-off
