Citation: Bao-Shou Shen, Hao Wang, Li-Jun Wu, Rui-Sheng Guo, Qing Huang, Xing-Bin Yan. All-solid-state flexible microsupercapacitor based on two-dimensional titanium carbide[J]. Chinese Chemical Letters, ;2016, 27(10): 1586-1591. doi: 10.1016/j.cclet.2016.04.012 shu

All-solid-state flexible microsupercapacitor based on two-dimensional titanium carbide

Bao-Shou Shen ^a,c ,
Hao Wang ^a ,
Li-Jun Wu ^a,c ,
Rui-Sheng Guo ^a ,
Qing Huang ^b,, ,
Xing-Bin Yan ^a,,

a.
Laboratory of Clean Energy Chemistry and Materials, State Key Laboratory of Solid Lubrication, Lanzhou Institute of Chemical Physics, Chinese of Academy of Sciences, Lanzhou 730000, China
b.
Division of Functional Materials and Nano-Devices, Ningbo Institute of MaterialTechnology and Engineering, Chinese Academy of Science, Ningbo 315201, China
c.
University of Chinese Academy of Sciences, Beijing 100039, ChinaUniversity of Chinese Academy of Sciences, Beijing 100039, China

Corresponding author: Qing Huang, huangqing@nimte.ac.cn Xing-Bin Yan, xbyan@licp.cas.cn
Received Date: 25 March 2016
Revised Date: 11 April 2016
Accepted Date: 14 April 2016
Available Online: 23 October 2016

Figures(5)

MXenes, serving as a novel family of two-dimensional (2D) metal carbides, have attracted great research interest as one of the promising electrode materials due to the unique properties. However, to our best knowledge, the 2D titanium carbide (one kind of MXene) used in constructing microsupercapacitors (MSCs) has not yet been reported to date. To this end, we firstly produce the MXene films on various kinds of substrates including polyethylene terephthalate (PET), silicon oxide film and titanium plate through vacuum-filtrating and subsequent controlled transferring. On this basis, flexible all-solid-state symmetric MSCs on PET substrate based on MXene films are fabricated by micro-fabrication process using polyvinyl alcohol (PVA)/H₂SO₄ as gel electrolyte. The results show that the as-made MSC has an ultrahigh rate performance with the scan rate of up to 1000 V s^-1 as well as an ultrafast frequency response (τ₀=0.5 ms). In addition, the MSC delivers a large volumetric capacitance of 1.44 F cm^-3, a high volumetric energy density (0.2 mWh cm^-3) at the current density of 0.288 A cm^-3 and a good cycling stability. Our research results presented here may pave the way for a new potential application of MXene in micro-power suppliers and micro-energy storage devices.
- MXene,
- Microsupercapacitors,
- Flexible,
- Frequency response,
- Scan rate,
- Volumetric capacitance
