Citation: HE Xiao-qiang, MO Wen-long, WANG Qiang, MA Feng-yun. Effect of swelling treatment by ionic liquid on the structure and pyrolysis performance of the direct coal liquefaction residue[J]. Journal of Fuel Chemistry and Technology, ;2019, 47(12): 1417-1429. shu

Effect of swelling treatment by ionic liquid on the structure and pyrolysis performance of the direct coal liquefaction residue

Key Laboratory of Coal Clean Conversion & Chemical Engineering Process(Xinjiang Uyghur Autonomous Region), College of Chemistry and Chemical Engineering, Xinjiang University, Urumqi 830046, China

Corresponding author: MO Wen-long, mowenlong@xju.edu.cn
Received Date: 12 August 2019
Revised Date: 17 September 2019

Fund Project: the National Natural Science Foundation of China 21276219The project was supported by the National Science Foundation of China-Key Project of Xinjiang Joint Foundation (U1503293) and the National Natural Science Foundation of China (21276219)the National Science Foundation of China-Key Project of Xinjiang Joint Foundation U1503293

Figures(13)

Direct coal liquefaction residue (DCLR) was swelled by four kinds of ionic liquids with the same anion and different organic chain length cations, [EMIM] [MeSO₄], [BMIM] [MeSO₄], [HMIM] [MeSO₄] and[OMIM] [MeSO₄], and the effects of swelling treatment with ionic liquids on swelling degree, surface morphology, functional group distribution, the main structure and pyrolysis performance of the direct coal liquefaction residue were analyzed by SEM, FT-IR and TG-DTG characterizations. The swelling results show that different chain length ionic liquid has different swelling degrees for the DCLR, and[HMIM] [MeSO₄] presents the best swelling effect with the swelling degree of 1.78. The FT-IR results indicate that the ionic liquid could destroy C-H bond in DCLR, leading to a change in relative content of aliphatic and aromatic compounds. The TG-DTG characterization demonstrates that the pyrolysis performance of the residue is greatly affected by the different organic chain length ionic liquid. And the[OMIM] [MeSO₄] ionic liquid is more favorable for the pyrolysis of the residue than others, with the weight loss rate of 47.5%. However, the pyrolysis performance of the residue is restrained by the[BMIM] [MeSO₄] ionic liquid, in which the weight loss rate is lower than that of DCLR (without swelling treatment). The pyrolysis kinetic data based on Coats-Redfern method show that the pyrolysis reaction for the direct coal liquid residue and the swelled ones at low temperature (180-480 ℃) obeys a second order law, while the third and fourth order law of reaction is more suitable for the residue pyrolysis at high temperature section (480-825 ℃). In addition, the activation energy of the pyrolysis process for the DCLR is altered obviously by swelling treatment with different organic length ionic liquid, the longer the chain length, the higher the pyrolysis activation energy.
- direct coal liquefaction residue,
- swelling treatment,
- ionic liquid,
- pyrolysis
