Citation: Li Lingli, Gao Xingfa. π-Electron Configurations of sp²-Carbon Molecules and Structural Models of Fullerenols[J]. Chemistry, ;2020, 83(4): 356-359. shu

π-Electron Configurations of sp²-Carbon Molecules and Structural Models of Fullerenols

Li Lingli ,
Gao Xingfa ^,

College of Chemistry and Chemical Engineering, Jiangxi Normal University, Nanchang, 330022

Corresponding author: Gao Xingfa, gaox@jxnu.edu.cn
Received Date: 20 December 2019
Accepted Date: 31 December 2019

Figures(6)

In this paper, our theoretical studies on the structures of fullerenols (including endohedral metallofullerenols) are reviewed. The traditional Clar model was innovated to predict chemical stabilities for sp²-carbon molecules containing heteroatoms, functional groups, and metals. Based on these results, the rule of chemical stability for fullerenols was developed. Using this stability rule, the distributions of functional groups of chemically stable fullerenols were predicted. By the combination of calculations and experiments, the species of functional groups of fullerenols were further characterized, and the precision structural models for fullerenols were established. A computer program was further written to automatically screen fullerenol structures with high chemical stabilities. The results will also help predict structures for the multi-addition derivatives of other sp² carbon materials.
- Fullerenols,
- Multiaddition reaction,
- π-conjugation,
- Chemical stability,
- Clar model
1. [1]
  Chiang L Y, Swirczewski J W, Hsu C S, et al. J. Chem. Soc. Chem. Commun., 1992, 24(24):35~51.
2. [2]
  Chiang L Y, Upasani R B, Swirczewski J W, et al. J. Am. Chem. Soc., 1993, 115(13):5453~5457.
3. [3]
  Wang Z, Wang S, Lu Z, et al. J. Cluster Sci., 2015, 26(2):375~388.
4. [4]
  Wu G, Gao X J, Jang J, et al. J. Mol. Model., 2016, 22(7):161~167.
5. [5]
  Li J, Chen L, Su H, et al. Nanoscale, 2019, 11(31):14528~14539.
6. [6]
  Meng J, Liang X, Chen X, et al. Integr. Biol. (Camb)., 2013, 5(1):43~47.
7. [7]
  Wang J, Hu Z, Xu J, et al. NPG Asia Mater., 2014, 6(2):e84~e84.
8. [8]
  Yan L, Zhao F, Li S, et al. Nanoscale, 2011, 3(2):362~382.
9. [9]
  Liu Y, Chen C, Qian P, et al. Nat. Commun., 2015, 6:5988~6006.
10. [10]
  Grebowski J, Krokosz A, Puchala M. Biochim. Biophys. Acta, 2013, 1828(9):2007~2014.
11. [11]
  Yin J J, Lao F, Fu P P, et al. Biomaterials, 2009, 30(4):611~621.
12. [12]
  Jiao F, Liu Y, Qu Y, et al. Carbon, 2010, 48(8):2231~2243.
13. [13]
  Gao X, Wang L, Ohtsuka Y, et al. J. Am. Chem. Soc., 2009, 131(28):9663~9669.
14. [14]
  Gao X, Zhou Z, Zhao Y, et al. J. Phys. Chem. C, 2008, 112:12677~12682.
15. [15]
  Zheng J J, X Zhao, Zhao Y, et al. Sci. Rep., 2013, 3:1271~1278.
16. [16]
  Clar E, The Aromatic Sextet, Wiley: London. 1972.
17. [17]
  Watson M D, Fechtenkotter A, Mullen K. Chem. Rev., 2001, 101(5):1267~1300.
18. [18]
  Tang Q, Zhou Z, Chen Z. Nanoscale, 2013, 5(11):4541~4583.
19. [19]
  Gao X, Zhang S B, Zhao Y, et al. Angew. Chem. Int. Ed., 2010, 49(38):6764~6767.
20. [20]
  Gao X, Wei Z, Meunier V, et al. Chem. Phys. Lett., 2013, 555:1~6.
21. [21]
  Gao X, Zhao Y, Liu B, et al. Nanoscale, 2012, 4(4):1171~1176.
22. [22]
  Gao X J, Chen B Z, Gao X. Carbon, 2016, 96, 980~986.
23. [23]
  Gao X J, Sun B, Zhao Y, et al. Dalton Transac., 2015, 44(20):9561~9568.
24. [24]
  Liu X, Li L, Liu B, et al. J. Phys. Chem. A, 2012, 116(47):11651~11655.
25. [25]
  Gao X J, Shen X, Chen B Z, et al. J. Phys. Chem. C, 2016, 120(21):11709~11715.
26. [26]
  Wang Z, Lu Z, Zhao Y, et al. Nanoscale, 2015, 7(7):2914~2925.
27. [27]
  Wang Z, Chang X, Lu Z, et al. Chem. Sci., 2014, 5(8):2940~2948.
