Citation: WU Jun-hong. Hydrothermal dewatering of lignite to improve the slurry-ability, rheology, and stability of coal-water slurry[J]. Journal of Fuel Chemistry and Technology, ;2019, 47(3): 271-278. shu

Hydrothermal dewatering of lignite to improve the slurry-ability, rheology, and stability of coal-water slurry

WU Jun-hong ^,

Zhejiang Development & Planning Institute, Hangzhou 310012, China

Corresponding author: WU Jun-hong, garywu@zju.edu.cn
Received Date: 15 October 2018
Revised Date: 13 January 2019

Figures(8)

Xiaolongtan lignite was upgraded by hydrothermal dewatering (HTD). The main factors affecting slurry-ability of the lignite including coal property, oxygen functional groups, surface hydrophilicity, and particle size distribution were analyzed. The effect of HTD on solid concentration, rheology, and stability of the upgraded coal was also investigated. The results show that a substantial amount of moisture was removed, oxygen content decreased, and the coal rank was enhanced by HTD upgrading. The contact angle between coal and water increased after removal of oxygen functional groups by HTD, thereby improving surface property of the upgraded lignite. A typical bimodal distribution of the lignite particle size was observed. The mean particle diameter of lignite decreased and the lignite particles became more regular after HTD. HTD upgrading significantly improved slurry-ability of the lignite. The solid concentration of raw coal was 44.09%, while that of the upgraded coal after HTD increased to 61.94%. The consistency coefficient K decreased, while the rheological index n increased for the CWS prepared from the upgraded coals. HTD upgrading decreased the apparent viscosity, and maintained the shear-thinning behavior of pseudo-plastic fluid. Moreover, as the water separation ratio decreased and formation of hard sedimentation was delayed, stability of the CWS was enhanced after HTD upgrading. Overall, the physico-chemical properties of Xiaolongtan lignite were significantly modified after HTD, thus a high-quality slurry fuel with high solid concentration, superior pseudo-plastic behavior, and good stability could be achieved.
- hydrothermal dewatering,
- lignite,
- coal-water slurry,
- slurry-ability,
- rheology
1. [1]
  BAI Xiang-fei. Discussion on utilization and development of improving quality technology of lignite and low rank bituminous coal in China[J]. Coal Qual Technol, 2010(6):9-11. doi: 10.3969/j.issn.1007-7677.2010.06.003
2. [2]
  WILLSON W G, WALSH D A N, IRWINC W. Overview of low-rank coal (LRC) drying[J]. Coal Prep, 1997,18(1/2):1-15.
3. [3]
  YU Yu-jie, LIU Jian-zhong, WANG Chuan-cheng, HU Ya-xuan, ZHOU Jun-hu, CEN Ke-fa. Status quo of development in dewatering for upgrading low rank coal[J]. Therm Power Gener, 2011,40(9):1-4. doi: 10.3969/j.issn.1002-3364.2011.09.001
4. [4]
  ZHANG Da-zhou, LU Wen-xin, CHEN Feng-jing, XIA Wu, ZUO Jing, WANG Zhi-gang, SHANG Kuan-xiang. Recent developments in recovery and utilization of water and heat from lignite dewatering[J]. Chem Ind Eng Prog, 2016,35(2):472-478.
5. [5]
  YU J, TAHMASEBI A, HAN Y, YIN F, LI X. A review on water in low rank coals:The existence, interaction with coal structure and effects on coal utilization[J]. Fuel Process Technol, 2013,106:9-20. doi: 10.1016/j.fuproc.2012.09.051
6. [6]
  WANG Chuan-cheng, LIU Jian-zhong, YU Yu-jie, LUO Lu-lin, CHENG Jun, ZHOU Jun-hu, CEN Ke-fa. Slurryability of coal water slurry prepared by Inner Mongolia brown coal[J]. Proc CSEE, 2010,30(S1):85-90.
7. [7]
  WU J, LIU J, YUAN S, ZHANG X, LIU Y, WANG Z, ZHOU J. Sulfur transformation during hydrothermal dewatering of low rank coal[J]. Energy Fuels, 2015,29(10):6586-6592. doi: 10.1021/acs.energyfuels.5b01258
8. [8]
  YU Y, LIU J, CEN K. Properties of coal water slurry prepared with the solid and liquid products of hydrothermal dewatering of brown coal[J]. Ind Eng Chem Res, 2014,53(11):4511-4517. doi: 10.1021/ie5000592
9. [9]
  MORIMOTO M, NAKAGAWA H, MIURA K. Low rank coal upgrading in a flow of hot water[J]. Energy Fuels, 2009,23(9):4533-4539. doi: 10.1021/ef9004412
10. [10]
  NONAKA M, HIRAJIMA T, SASAKI K. Upgrading of low rank coal and woody biomass mixture by hydrothermal treatment[J]. Fuel, 2011,90(8):2578-2584. doi: 10.1016/j.fuel.2011.03.028
11. [11]
  LIU J, WU J, ZHU J, WANG Z, ZHOU J, CEN K. Removal of oxygen functional groups in lignite by hydrothermal dewatering:An experimental and DFT study[J]. Fuel, 2016,178:85-92. doi: 10.1016/j.fuel.2016.03.045
12. [12]
  UMAR D F, SANTOSO B, USUI H. The effect of upgrading processes on combustion characteristics of berau coal[J]. Energy Fuels, 2007,21(6):3385-3387. doi: 10.1021/ef070061j
13. [13]
  LIU M, LI J, DUAN Y. Effects of solvent thermal treatment on the functional groups transformation and pyrolysis kinetics of Indonesian lignite[J]. Energy Convers Manage, 2015,103:66-72. doi: 10.1016/j.enconman.2015.06.047
14. [14]
  GE Li-chao, ZHANG Yan-wei, YING Zhi, WANG Zhi-hua, ZHOU Jun-hu, CEN Ke-fa. Influence of the hydrothermal dewatering on the gasification characteristics of typical Chinese lignite[J]. Proc CSEE, 2013,33(32):14-20.
15. [15]
  GE L, ZHANG Y, XU C, WANG Z, ZHOU J, CEN K. Influence of the hydrothermal dewatering on the combustion characteristics of Chinese low-rank coals[J]. Appl Therm Eng, 2015,90:174-181. doi: 10.1016/j.applthermaleng.2015.07.015
16. [16]
  SONG Cheng-jian, QU Jian-lin, YANG Zhi-yuan, WANG Guang-heng, YANG Fu-sheng, ZHOU An-ning. Matching rules between dispersants and Shenfu coal slurryability[J]. J Chem Ind Eng, 2016,67(9):3965-3971.
17. [17]
  YU Chi-wei, LI Bao-qing, LI Wen, CHEN Hao-kan. Study on the properties of coal water slurry prepared with different coal ranks[J]. J Fuel Chem Technol, 2005,33(2):155-160. doi: 10.3969/j.issn.0253-2409.2005.02.006
18. [18]
  GENG W, KUMABE Y, NAKAJIMA T, TAKANASHI H, OHKI A. Analysis of hydrothermally-treated and weathered coals by X-ray photoelectron spectroscopy (XPS)[J]. Fuel, 2009,88(4):644-649. doi: 10.1016/j.fuel.2008.09.025
19. [19]
  KADIOGLU Y, VARAMAZ M. The effect of moisture content and air-drying on spontaneous combustion characteristics of two Turkish lignites[J]. Fuel, 2003,82(13):1685-1693. doi: 10.1016/S0016-2361(02)00402-7
20. [20]
  LIU Meng, CHEN Liang-yong, DUAN Yu-feng. Influence of concentration and particle size distribution on viscosity prediction of coal slurry[J]. J Fuel Chem Technol, 2009,37(3):266-270. doi: 10.3969/j.issn.0253-2409.2009.03.003
21. [21]
  GAO Zhi-fang, ZHU Shu-quan, WU Xiao-hua. Lignite upgrading modification affected to features of coal water mixture[J]. Coal Sci Technol, 2010,38(9):112-116.
22. [22]
  LIU Yu, LI Wei-dong, LIU Hai-feng. Co-slurry ability of dried sewage sludge and Shenfu coal[J]. J Fuel Chem Technol, 2010,38(6):656-659. doi: 10.3969/j.issn.0253-2409.2010.06.004
23. [23]
  LIU Ming-qiang, LIU Jian-zhong, WANG Rui-kun, ZHOU Jun-hu, CEN Ke-fa. Effects of pyrolysis temperature on slurry ability of lignite semi-coke[J]. Proc CSEE, 2013,33(8):36-43.
24. [24]
  ROH N S, SHIN D H, KIM D C, KIM J D. Rheological behavior of coal-water mixtures.1. Effects of coal type, loading and particle-size[J]. Fuel, 1995,74(8):1220-1225. doi: 10.1016/0016-2361(95)00041-3
25. [25]
  WU J H, LIU J Z, YU Y J, WANG R K, ZHOU J H, CEN K F. Improving slurryability, rheology, and stability of slurry fuel from blending petroleum coke with lignite[J]. Pet Sci, 2015,12(1):157-169. doi: 10.1007/s12182-014-0008-3
26. [26]
  LIU Meng, DUAN Yu-feng, LI Hua-feng, MA Xiu-yuan. Analysis on co-slurryability and rheology of modified sludge and petroleum coke[J]. Proc CSEE, 2012,32(35):59-65.
