Citation: ZHANG Li-qiang, LI Kai, ZHU Xi-feng. Two-step pyrolysis characteristics of bean stalks[J]. Journal of Fuel Chemistry and Technology, ;2016, 44(5): 534-539. shu

Two-step pyrolysis characteristics of bean stalks

Anhui Province Key Laboratory of Biomass Clean Energy, University of Science and Technology of China, Hefei 230026, China

Corresponding author: ZHU Xi-feng, xfzhu@ustc.edu.cn
Received Date: 21 December 2015
Revised Date: 22 February 2016

Fund Project: the Key Research Program of the Chinese Academy of Sciences KGZD-EW-304-3the Major State Basic Research Development Program of China 2013CB228103the Major State Basic Research Development Program of China 973 program

Figures(6)

Two-step pyrolysis of soybean stalk was investigated using pyrolysis-gas chromatography/mass spectrometry (Py-GC/MS). The results indicate that with the increase of the first-step pyrolysis temperature (t₁), the total peak area of the first-step products becomes higher. However, for the second-step, the total peak area decreases gradually with the increase of t₁. The products in the first-step pyrolysis have higher contents of acids, ketones and furans when t₁ is 400 or 450 ℃. This is because that the products are originated from cellulose and hemicellulose. The content of hydrocarbon products in the second-step is more than 20% when t₁ is 450 or 500 ℃. With two-step pyrolysis some products with high content can be obtained in the first or second step, respectively, such as acetic acid, furfural, guaiacol, methylbenzene and benzene etc., thus preliminarily achieving the selective pyrolysis of biomass.
- two-step pyrolysis,
- selective pyrolysis,
- Py-GC/MS,
- soybean stalk
1. [1]
  WEI Xin-lai, WANG Zhi, RUAN Ren-xiang, ZHANG Ying. Progress in chemical transformation of lignocellulosic biomass degradation products[J]. Mod Chem Ind, 2010,30(12):26-31.
2. [2]
  WANG Zhi. Selective catalytic pyrolysis of biomass for high value-added chemicals[D]. Hefei: University of Science and Technology of China, 2010.
3. [3]
  CARLSON T R, VISPUTE T P, HUBER G W. Green gasoline by catalytic fast pyrolysis of solid biomass derived compounds[J]. ChemSusChem, 2008,1(5):397-400. doi: 10.1002/(ISSN)1864-564X
4. [4]
  LI Kai, ZHENG Yan, LONG Tan, ZHU Xi-feng. Study on effect of temperature and time on biomass pyrolysis by Py-GC/MS[J]. J Fuel Chem Technol, 2013,41(7):845-849.
5. [5]
  CHANG Sheng, ZHAO Zeng-li, ZHENG An-qing, LI Hai-bin. Step-wise catalytic pyrolysis of fir using pyrolysis-gas chromatography/mass spectrometry[J]. Trans Chin Soc Agric Mach, 2010,41(6):93-97.
6. [6]
  HAMMER N L, GARRIDO R A, STARCEVICH J, COE C G, SATRIO J A. Two-step pyrolysis process for producing high quality bio-oils[J]. Ind Eng Chem Res, 2015,54(43):10629-10637. doi: 10.1021/acs.iecr.5b02365
7. [7]
  HUANG Y B, WEI L, JULSON J, GAO Y, ZHAO X H. Converting pine sawdust to advanced biofuel over HZSM-5 using a two-stage catalytic pyrolysis reactor[J]. J Anal Appl Pyrolysis, 2015,111:148-155. doi: 10.1016/j.jaap.2014.11.019
8. [8]
  ZHANG Hai-rong, PANG Hao, SHI Jin-zhi, LIAO Bing. TG study on major biomass components and its liquefied residues from pyrolysis[J]. Chem Ind Eng Prog, 2011,30(10):2194-2199.
9. [9]
  QU Yan-chao. Low temperature selective pyrolysis of herbage biomass for 4-vinylphenol[D]. Hefei: University of Science and Technology of China, 2013.
10. [10]
  ZHU Xi-feng. Preparation and Application of Bio-oil[M]. Beijing: Chemical Industry Press, 2013.
11. [11]
  PATTIYA A, TITILOVE J O, BRIDGWATER A V. Fast pyrolysis of cassava rhizome in the presence of catalysts[J]. J Anal Appl Pyrolysis, 2008,81(1):72-79. doi: 10.1016/j.jaap.2007.09.002
12. [12]
  LU Qiang, ZHANG Dong, ZHU Xi-feng. Catalytic effects of four metal chlorides on fast pyrolysis of cellulose (Ⅰ) Py-GC/MS experiments[J]. CIESC J, 2010,61(4):1018-1024.
13. [13]
  CHEN W H, KUO P C. Isothermal torrefaction kinetics of hemicellulose, cellulose, lignin and xylan using thermogravimetric analysis[J]. Energy, 2011,36(11):6451-6460. doi: 10.1016/j.energy.2011.09.022
14. [14]
  YANG Xiao-chu. Study on the characteristics of biomass two-step pyrolysis[D]. Beijing: North China Electric Power University, 2012.
15. [15]
  EVANS R J, MILNE T A, SOLTYS M N. Direct mass-spectrometric studies of the pyrolysis of carbonaceous fuels: Ⅲ Primary pyrolysis of lignin[J]. J Anal Appl Pyrolysis, 1986,9(3):207-236. doi: 10.1016/0165-2370(86)80012-2
16. [16]
  DARVELL L I, BRINDLEY C, BAXTER X C, JONES J M, WILLIAMS A. Nitrogen in biomass char and its fate during combustion-a model compound approach[J]. Energy Fuels, 2012,26(11):6482-6491.
17. [17]
  WU Yi-min, ZHAO Zeng-li, WU Wen-qiang, LI Hai-bin. Step-pyrolysis of biomass using pyrolysis-gas chromatography/mass spectrometry[J]. J Fuel Chem Technol, 2010,38(2):168-173.
18. [18]
  ZHAO Shi-xiang, JI Qiang, LI Zhong-hui, WANG Xu-dong. Characteristics and mineralization in soil of apple-derived biochar produced at different temperature[J]. Trans Chin Soc Agric Mach, 2015,46(6):183-192.
19. [19]
  ALÉN R, KUOPPALA E, OESCH P. Formation of the main degradation compound groups from wood and its components during pyrolysis[J]. J Anal Appl Pyrolysis, 1996,36(2):137-148. doi: 10.1016/0165-2370(96)00932-1
20. [20]
  WANG Shu-rong, LUO Zhong-yang. Pyrolysis of Biomass Components[M]. Beijing: Science Press, 2013.
