Citation: BU Yan, ZHAO Guo-li, WANG Shao-jun, LING Feng-xiang, ZHANG Cheng. Effect of silica promoter on the structure of CoMo/Al₂O₃-SiO₂ catalysts[J]. Journal of Fuel Chemistry and Technology, ;2016, 44(4): 463-469. shu

Effect of silica promoter on the structure of CoMo/Al₂O₃-SiO₂ catalysts

Fushun Research Institute of Petroleum and Petrochemicals, SINOPEC, Fushun 113001, China

Corresponding author: ZHAO Guo-li, zhaoguoli.fshy@sinopec.com
Received Date: 20 August 2015
Revised Date: 27 January 2016

Figures(8)

The characterization of a series of CoMo/Al₂O₃-SiO₂ catalysts with different SiO₂ contents were studied using in-situ FT-IR, Raman, UV-Vis and H₂-TPR techniques. The results show that the increase of the silica component in CoMo/Al₂O₃-SiO₂ catalysts can promote the transformation of octahedral molybdenum species into tetrahedral molybdenum species, and the higher SiO₂ content can contribute to the transformation. Proper amount of silica component in the mixed supports can alter the interaction between the support and the active metals, resulting in higher hydrodesulfurization(HDS) activity of CoMo/Al₂O₃-SiO₂ catalysts.
- CoMo/Al₂O₃-SiO₂,
- in-situ FT-IR spectroscopy,
- CO adsorption,
- sulfidation
1. [1]
  ZHENG Yu-yin, LIU Bai-jun. Recent advances in development of hydrotreating catalysts[J]. Ind Catal, 2003,11(7):1-5.
2. [2]
  ZHANG Yu-han, LING Feng-xiang, WANG Shao-jun, ZHAO Guo-li. In-situ FTIR studies of Co-Mo/-Al₂O₃ catalysts[J]. J Fuel Chem Technol, 2013,41(6):710-714.
3. [3]
  PAROLA V, DEGANELLO G, VENEZIA A M. CoMo catalysts supported on aluminosilicates: synergy between support and sodium effects[J]. Appl Catal A: Gen, 2004,260(2):237-247. doi: 10.1016/j.apcata.2003.10.020
4. [4]
  AL-DALAMA K, STANISLAUS A. A Comparative study of the influence of chelating agents on the hydrodesulfurization(HDS) activity of alumina and silica-alumina-supported CoMo catalysts[J]. Energy Fuels, 2006,20(5):1777-1783. doi: 10.1021/ef060125a
5. [5]
  ZEPEDA T A, PAWELEC B, FIERRO J L G, OLIVAS A, FUENTES S, HALACHEV T. Effect of Al and Ti content in HMS material on the catalytic activity of NiMo and CoMo hydrotreating catalysts in the HDS of DBT[J]. Microporous Mesoporous Mater, 2008,111(1/3):157-170.
6. [6]
  WU Yu-hang, LING Feng-xiang, ZHAO Guo-li, WANG Shao-jun. An In-situ FT-IR study on the CoMo/Al₂O₃-SiO₂ catalysts[J]. Contemp Chem Ind, 2015,44(5):962-964.
7. [7]
  VAKROS J, LYCOURGHIOTIS A, VOYIATZIS G A, SIOKOU A, KORDULIS C. CoMo/Al₂O₃-SiO₂ catalysts prepared by co-equilibrium deposition filtration: Characterization and catalytic behavior for the hydrodesulphurization of thiophene[J]. Appl Catal B: Environ, 2010,96(3/4):496-507.
8. [8]
  EISCHENS R P, PLISKIN W A. The infrared spectra of adsorbed molecules[J]. Adv Catal, 1958,10:1-56.
9. [9]
  MORTERRA C, BOLIS V, MAGNACCA G. IR spectroscopic and microcalorimetric characterization of lewis acid sites on (transition phase) Al₂O₃ using adsorbed CO[J]. J Am Chem Soc, 1994,10(6):1812-1824.
10. [10]
  MAUGÉF , LAVALLEY J C. FT-IR study of co adsorption on sulfided Mo/Al₂O₃ unpromoted or promoted by metal carbonyls: Titration of sites[J]. J Catal, 1992,137(1):69-76. doi: 10.1016/0021-9517(92)90139-9
11. [11]
  DUJARDIN C, LÉLIAS M A, GESREL J, TRAVERT A, DUCHET J C, MAUGE F. Towards the characterization of active phase of (Co)Mo sulfide catalysts under reaction conditions[J]. Appl Catal A: Gen, 2007,322(1):46-57.
12. [12]
  MESTL G, SRINIVASAN T K K. Raman spectroscopy of monolayer-type catalysts: Supported molybdenum oxides[J]. Cat Rev: Sci Eng, 1998,40(4):451-570. doi: 10.1080/01614949808007114
13. [13]
  PAPADOPOULOU C, VAKROS J, MATRALIS H K, KORDULIS C, LYCOURGHIOTIS A. On the relationship between the preparation method and the physicochemical and catalytic properties of the CoMo/-Al₂O₃ hydrodesulfurization catalysts[J]. J Colloid Interface Sci, 2003,261(1):146-153. doi: 10.1016/S0021-9797(02)00167-4
14. [14]
  BERGWERFF J A, JANSEN M, LELIVELD B G, VISSER T, DE JONG K, WECKHUYSEN B. Influence of the preparation method on the hydrotreating activity of MoS₂/Al₂O₃ extrudates: A Raman microspectroscopy study on the genesis of the active phase[J]. J Catal, 2006,243(2):292-302. doi: 10.1016/j.jcat.2006.07.022
15. [15]
  CHRISTODOULAKIS A, HERACLEOUS E, LEMONIDOU A A, BOGHOSIAN S. An operando Raman study of structure and reactivity of alumina-supported molybdenum oxide catalysts for the oxidative dehydrogenation of ethane[J]. J Catal, 2006,242(1):16-25.
16. [16]
  JEZIOROWSKI H, KNOEZINGER H, GRANGE P, GAJARDO P. Raman spectra of cobalt molybdenum oxide supported on silica[J]. J Phys Chem, 1980,84(14):1825-1829. doi: 10.1021/j100451a017
17. [17]
  NIKOLOVA D, EDREVA-KARDJIEVA R, GIURGINCA M, MEGHEA A, VAKROS J, VOYIATZIS G A, KORDULIS C. The effect of potassium addition on the state of the components in the oxide precursor of the (Ni)(Mo)/-Al₂O₃ water-gas shift catalysts: FT-IR, diffuse reflectance and Raman spectroscopic studies[J]. Vib Spectrosc, 2007,44(2):343-350. doi: 10.1016/j.vibspec.2007.03.002
18. [18]
  VAKROS J, BOURIKAS K, KORDULIS C, LYCOURGHIOTIS A. Influence of the impregnation ph on the surface characteristics and the catalytic activity of the Mo/γ-Al₂O₃ and CoMo/γ-Al₂O₃ hydrodesulfurization catalysts prepared by equilibrium deposition filtration (EDF)[J]. J Phys Chem B, 2003,107(8):1804-1813. doi: 10.1021/jp020953e
19. [19]
  VAN DE WATER L G A, BERGWERFF J A, LELIVELD G, WECKHUYSEN B M, DE JONG K. Insights into the preparation of supported catalysts: A spatially resolved raman and UV-Vis spectroscopic study into the drying process of CoMo/γ-Al₂O₃ catalyst bodies[J]. J Phys Chem B, 2005,109(30):14513-14522. doi: 10.1021/jp051037e
20. [20]
  VAN DE WATER L G A, BERGWERFF J A, NIJHUIS T A, DE JONG K P, WECKHUYSEN B M. UV-Vis microspectroscopy: Probing the initial stages of supported metal oxide catalyst preparation[J]. J Am Chem Soc, 2005,127(14):5024-5025. doi: 10.1021/ja044460u
21. [21]
  PORTELA L, GRANGE P, DELMON B. The adsorption of nitric oxide on supported Co-Mo hydrodesulfurization catalysts: A review[J]. Catal Rev: Sci Eng, 1995,37(4):699-731. doi: 10.1080/01614949508006452
22. [22]
  QU L, ZHANG W, KOOYMAN P J, PRINS R. MAS NMR, TPR, and TEM studies of the interaction of NiMo with alumina and silica-alumina supports[J]. J Catal, 2003,215(1):7-13. doi: 10.1016/S0021-9517(02)00181-1
23. [23]
  HENSEN E J M, WENDLANDT K P, VALYON J, BORNMANN P. Structure of MoO₃/Al₂O₃-SiO₂ catalysts[J]. Appl Catal, 1991,69(1):205-220. doi: 10.1016/S0166-9834(00)83303-5
24. [24]
  ARNOLDU P, DE JONGE J C M, MOULUN J A. Temperature-programed reduction of molybdenum(VI) oxide and molybdenum(IV) oxide[J]. J Phys Chem, 1985,89(21):4517-4526. doi: 10.1021/j100267a021
25. [25]
  RAJAGOPAL S, MARNIH J, MARZARI J A, MIRANDA R. Silica-alumina-supported acidic molybdenum catalysts-TPR and XRD characterization[J]. J Catal, 1994,147(2):417-428.
26. [26]
  MARZARI J A, RAJAGOPAL S, MIRANDA R. Bifunctional mechanism of pyridine hydrodenitrogenation[J]. J Catal, 1995,156(2):255-264. doi: 10.1006/jcat.1995.1252
