Citation: ZHOU Guang-lin, CHEN Sheng, LI Qin, JIANG Wei-li, ZHOU Hong-jun, GONG Xue-cheng. Impact of Ni content on the structure and adsorption desulfurization performance of Ni/ZnO-TiO₂ adsorbent[J]. Journal of Fuel Chemistry and Technology, ;2019, 47(8): 987-992. shu

Impact of Ni content on the structure and adsorption desulfurization performance of Ni/ZnO-TiO₂ adsorbent

1.
College of New Energy and Materials, China University of Petroleum, Beijing 102249, China;
2.
Beijing Key Laboratory of Biogas High Value Utilization, Beijing 102249, China

Corresponding author: ZHOU Guang-lin, zhouguanglin2@163.com
Received Date: 9 April 2019
Revised Date: 21 June 2019

Figures(6)

Using ZnO-TiO₂ as a carrier support, Ni/ZnO-TiO₂ gasoline desulfurization adsorbents with different Ni contents were prepared by equal volume impregnation method and characterized by X-ray diffraction (XRD), Mercury intrusion porosimetry, H₂-temperature-programmed desorption(H₂-TPD) and H₂-temperature-programmed reduction (H₂-TPR). Meanwhile, the desulfurization performance of the Ni/ZnO-TiO₂ adsorbents were evaluated using FCC light gasoline in a fixed bed reactor. The results show that proper increase of Ni content has little effect on the specific surface area, internal pore distribution and particle strength of the adsorbent, and can increase the Ni⁰ species with desulfurization activity and promote the desulfurization activity of the adsorbent. When the content of Ni in the adsorbent is too much, the internal pore distribution of the adsorbent changes, and the specific surface area and particle strength of the adsorbent are greatly reduced, which is extremely detrimental to the desulfurization activity of the adsorbent. When the Ni content is 4.45%, having the best desulfurization performance, can reduce the total sulfur content of 3×10^-4 in FCC light gasoline to below 5×10^-6, and maintain the desulfurization time up to 152 h, and the breakthrough sulfur capacity is 11.24% (112.4 mg S/g adsorbent). And the olefin content of FCC light gasoline after desulfurization changes little.
- FCC light gasoline,
- desulfurization adsorbent,
- Ni/ZnO-TiO₂,
- Ni content
1. [1]
  QIAN Bo-zhang. Production process and technological progress of clean gas and diesel oil(Ⅰ)[J]. Lubes Fuels, 2015,25(5):1-5.
2. [2]
  KHARE, GYANESH P, BARTLESVILL E. Desulfurization process and novel bimetallic sorbent systems for same: US, 6274533[P]. 2001-8-14.
3. [3]
  HUANG L C, WANG G F, QIN Z F, DONG M, DU M X, GE H, LI X K, ZHAO Y D, ZHANG J, HU T D, WANG J G. In situ XAS study on the mechanism of reactive adsorption desulfurization of oil product over Ni/ZnO[J]. Appl Catal B:Environ, 2011,106(1):26-38.
4. [4]
  ZHAO L, CHEN Y, GAO J S, CHEN Y. Desulfurization mechanism of FCC gasoline:A review[J]. Front Chem Sci Eng, 2010,4(3):314-321. doi: 10.1007/s11705-009-0271-9
5. [5]
  HUANG L X, WANG G F, QIN Z F, DU M X, DONG M, GE H, WU Z W, ZHAO Y D, MA C Y, HU T D, WANG J G. A sulfur K-edge XANES study on the transfer of sulfur species in the reactive adsorption desulfurization of diesel oil over Ni/ZnO[J]. Catal Commun, 2010,11(7):592-596. doi: 10.1016/j.catcom.2010.01.001
6. [6]
  RYZHIKOV A, BEZVERKHYY I, BELLAT J P. Reactive adsorption of thiophene on Ni/ZnO:Role of hydrogen pretreatment and nature of the rate determining step[J]. Appl Catal B:Environ, 2008,84(3):766-772.
7. [7]
  PETZOLD F G, JASINSKI J, CLARK E L, KIM J H, ABSHER J, TOUFAR H, SUNKARA M K. Nickel supported on zinc oxide nanowires as advanced hydrodesulfurization catalysts[J]. Catal Today, 2012,198(1):219-227.
8. [8]
  ZHANG Y L, YANG Y X, HAN H X, YANG M, WANG L, ZHANG Y N, JANG Z X, LI C. Ultra-deep desulfurization via reactive adsorption on Ni/ZnO:The effect of ZnO particle size on the adsorption performance[J]. Appl Catal B:Environ, 2012,119/120:13-19. doi: 10.1016/j.apcatb.2012.02.004
9. [9]
  HUSSAIN A H M S, TATARCHUK B J. Adsorptive desulfurization of jet and diesel fuels using Ag/TiO_x-Al₂O₃ and Ag/TiO_x-SiO₂ adsorbents[J]. Fuel, 2013,107(9):465-473.
10. [10]
  RANA M S, MAITY S K, ANCHEYTA J, DHAR G M, RAO T S R P. TiO₂-SiO₂ supported hydrotreating catalysts:physico-chemical characterization and activities[J]. Appl Catal A:Gen, 2003,253(1):165-176. doi: 10.1016/S0926-860X(03)00502-7
11. [11]
  STRANICK M A, HOUALLA M, HERCULES D M. The influence of TiO₂ on the speciation and hydrogenation activity of Co/Al₂O₃catalysts[J]. J Catal, 1990,125(1):214-226.
12. [12]
  DENG Cun, DUAN Lian-yun, XU Xian-ping, XIE You-chang. Preparation of composite carrier TiO₂/SiO₂ by gas adsorption and dispersion of MoO₃ on its surface[J]. Chin J Catal, 1993,14(4):281-286.
13. [13]
  ROH H S, JUN K W, DONG W S, CHANG J S, PARK S E, JOE Y I. Highly active and stable Ni/Ce-ZrO₂, catalyst for H₂, production from methane[J]. J Mol Catal A:Chem, 2002,181(1):137-142.
14. [14]
  ULLAH R, BAI P, WU P P, ETIM U J, ZHANG J Q, HAN D Z, SUBHAN F, ULLAH S, ROOD M J, YAN Z F. Superior performance of freeze-dried Ni/ZnO-Al₂O₃ adsorbent in the ultra-deep desulfurization of high sulfur model gasoline[J]. Fuel Process Technol, 2016,156:505-514.
15. [15]
  GOICOECHEA S, KRALEVA E, SOKOLOV S, SCHNEIDER M, POHI M M, KOCKMANN N, EHRICH H. Support effect on structure and performance of Co and Ni catalysts for steam reforming of acetic acid[J]. Appl Catal A:Gen, 2016,514:182-191. doi: 10.1016/j.apcata.2015.12.025
16. [16]
  XIONG Jun, CHEN Ji-xiang, ZHANG Ji-yan. Influence of Ni loading on properties of Ni/TiO₂ catalyst for hydrogenation of o-chloronitrobenzene to o-chloroaniline[J]. Chin J Catal, 2006,27(7):579-584. doi: 10.3321/j.issn:0253-9837.2006.07.011
17. [17]
  TANG Ming-xing, LI Xue-kuan, LÜ Zhan-jun, GE Hui, ZHOU Li-gong. Ultra-deep hydrodesulfurization of benzene over Ni/ZnO catalyst[J]. J Fuel Chem Technol, 2009,37(6):707-712. doi: 10.3969/j.issn.0253-2409.2009.06.012
18. [18]
  FERNANDES D M, SCOFIELD C F, NETO A A, CARDOSO M J B, ZOTIN J L, ZOTIN F M Z. The hydrogen adsorption capacity of commercial Pd/Rh and Pt/Rh automotive catalysts and its relationship to their activity[J]. Chem Eng J, 2012,189/190:62-67. doi: 10.1016/j.cej.2012.02.024
19. [19]
  YANG Xia, TIAN Da-yong, SUN Shou-li, SUN Qi. Influence of zirconia-alumina composite on catalytic performance of nickel-based catalysts for methanation[J]. Chem Ind Eng Prog, 2014,33(3):673-678.
20. [20]
  VELU S, GANGWAL S K. Synthesis of alumina supported nickel nanoparticle catalysts and evaluation of nickel metal dispersions by temperature programmed desorption[J]. Solid State Ionics, 2006,177(7/8):803-811.
21. [21]
  ISHIKAWA H, KONDO J N, DOMEN K. Hydrogen adsorption on Ru/ZrO₂ studied by FT-IR[J]. J Phys Chem B, 1999,103(16):3229-3234. doi: 10.1021/jp9842852
22. [22]
  WANG D H, QIAN W H, ISHIHARA A, KABE T. Elucidation of sulfidation state and hydrodesulfurization mechanism on TiO₂ catalysts using 35S radioisotope tracer methods[J]. J Catal, 2001,203(2):322-328. doi: 10.1006/jcat.2001.3349
