Citation: JING Zhong-yu, ZHANG Tao-qi, SHANG Jiang-wei, ZHAI Ming-lu, YANG Hao, QIAO Cong-zhen, MA Xin-qi. Influence of Cu and Mo components of γ-Al₂O₃ supported nickel catalysts on hydrodeoxygenation of fatty acid methyl esters to fuel-like hydrocarbons[J]. Journal of Fuel Chemistry and Technology, ;2018, 46(4): 427-440. shu

Influence of Cu and Mo components of γ-Al₂O₃ supported nickel catalysts on hydrodeoxygenation of fatty acid methyl esters to fuel-like hydrocarbons

1.
College of Chemistry and Chemical Engineering, Henan Province Engineering Research Center of Resource & Energy Recovery from Waste, Henan University, Kaifeng 475004, China
2.
Department of Automotive, City University of Zhengzhou, Zhengzhou 450000, China

Corresponding author: QIAO Cong-zhen, qiaocongzhen@henu.edu.cn
Received Date: 18 January 2018
Revised Date: 28 February 2018

Fund Project: Science and Technology Development Project of Henan Province 152102210258National Science and Technology Supporting Program 2013BAB11B02The project was supported by National Science and Technology Supporting Program (2013BAB11B02) and Science and Technology Development Project of Henan Province (152102210258)

Figures(15)

In this work, series of Ni/γ-Al₂O₃ catalysts with or without Cu and Mo components were prepared, characterized and tested for the hydrodeoxygenation of fatty acid methyl esters (FAME) to hydrocarbons. The effects of Cu and Mo loading, impregnation sequence with sequential impregnation and co-impregnation involved and reaction conditions on catalytic performance were investigated. According to the TG data, the spent 20Ni-6Cu/γ-Al₂O₃ catalyst gives less weight loss than the spent 20Ni/γ-Al₂O₃ catalyst, which indicates that the addition of copper inhibits the carbon deposits behavior on catalyst surface during reaction. For 20Ni-6Cu/γ-Al₂O₃ and 20Ni-6Cu-nMo/γ-Al₂O₃(n=2, 5, 8 and 12) catalysts, NH₃-TPD analysis shows that the addition of molybdenum phase has significant impact on the acid sites of γ-Al₂O₃. When the loading of molybdenum is 5%, a new acid site is observed corresponding to the medium strength acid site. The Cu and Mo modified catalysts demonstrate better catalytic performance than Ni/γ-Al₂O₃ catalysts. Based on XPS results, Cu in the catalysts exists in the Cu²⁺ and Mo in the catalysts has two states:Mo⁴⁺ and Mo⁶⁺, and different impregnation sequences may influence the actual element composition of active phase on the surface of catalysts. In addition, the conversion of FAME and yield of alkane are related to the catalysts prepared with different impregnation sequence. Among all the catalysts, the trimetallic 20Ni-6Cu-5Mo/γ-Al₂O₃ prepared by sequential impregnation (the former Ni and Cu impregnation, the latter Mo impregnation) exhibits optimal catalytic performance. Under appropriate reaction conditions 350℃, 2.5 MPa, WSHV=2.0 h^-1, H₂/oil ratio=1250 mL/mL, the conversion of FAME and yield of alkane are 98.4% and 94.2%.
- hydrodeoxygenation,
- fatty acid methyl esters,
- Ni-based catalysts,
- γ-Al₂O₃
