Citation: AISHA· Nulahong, MO Wen-long, MA Feng-yun. Effect of preparation parameters on the gold particle size of Au/HZSM-5[J]. Journal of Fuel Chemistry and Technology, ;2016, 44(6): 710-717. shu

Effect of preparation parameters on the gold particle size of Au/HZSM-5

Key Laboratory of Coal Clean Conversion & Chemical Engincering Process (Xinjiang Uyghur Autonomous Region), College of Chemistry and Chemical Engineering, Xin Jiang University, Urumqi 830046, China

Corresponding author: AISHA· Nulahong, aisa705@163.com
Received Date: 17 December 2015
Revised Date: 18 March 2016

Figures(10)

A serial of Au/HZSM-5 samples were prepared by vacuum deposition precipitation, cation exchange and vacuum sulfhydryl protection method. The effect of different preparation method, calcination temperature, calcination atmosphere and addition of potassium on the particle size and distribution of gold was invetigated. Based on the characterization of X-ray diffraction, ultraviolet-visible diffuse reflectance spectroscopy and transmission electron microscope, it was found that the gold particle size of Au/HZSM-5 was changed greatly with different preparation methods. Gold particle size (about 2-5nm) of Au/HZSM-5 prepared by vacuum sulfhydryl protection was obviously smaller than that of the other preparation methods. Taken Au/HZSM-5 catalyst prepared by vacuum deposition precipitation as an example, low calcination temperature and inert atmosphere (nitrogen and argon) were favorable to the good dispersion of gold particles. The activities and carbonylation selectivities of syngas on Au/HZSM-5 catalysts were evaluated by a micro-fixed pulse reactor. 48% of syngas conversion and 52% of methyl acetate selectivity were obtained at reaction temperature of 350℃ over Au/HZSM-5 catalysts with 1.86% Au loading, calcined in air, while 59% and 70% were obtained over catalyst calcined in argon. By contrast, 67% of syngas conversion and 78% of methyl acetate selectivity were obtained over the catalyst calcined in nitrogen plasma.
- Au/HZSM-5,
- gold particle,
- calcination temperature,
- calcination atmosphere,
- carbonylation
1. [1]
  HARUTA M, KOBAYASHI T, SANO H, YAMADA N. Novel gold catalysts for the oxidation of carbon-monoxide at a temperature far below 0℃[J]. Chem Lett, 1987,16(2):405-408. doi: 10.1246/cl.1987.405
2. [2]
  PESTRYAKOV A, BOGDANCHIKOVA N, SIMAKOV A, TUZOVSKAYA I, JENTOFT F, MAFISA M, DIAZ A. Catalytically active gold clusters and nanoparticles for CO oxidation[J]. Surf Sci, 2007,601(18):3792-3795. doi: 10.1016/j.susc.2007.04.012
3. [3]
  SIMAKOV A, TUZOSKAYA I, BOGDANCHIKOVA N, PESTRYAKOV A, AVALOS M, FARIAS M H, MAFISA M, SMOLENTSEVA E. Influence of sodium on activation of gold species in Y-zeolites[J]. Catal Commun, 2008,9(6):1277-1281. doi: 10.1016/j.catcom.2007.11.027
4. [4]
  DING Xiao-tao, ZHANG Pei-qing, AN Li-dun, QI Cai-xia. Progress in research of microporous zeolites supported nano-gold catalysts[J]. J Mol Catal, 2010,24(1):93-98.
5. [5]
  BLOCK B P, BAILAR J C. The reaction of gold (Ⅲ) with some bidentate co rdinating groups1[J]. J Am Chem Soc, 1951,73(10):4722-4725. doi: 10.1021/ja01154a071
6. [6]
  ZHENG N, FAN J, STUCKY G D. One-step one-phase synthesis of monodisperse noble-metallic nanoparticles and their colloidal crystals[J]. J Am Chem Soc, 2006,128(20):6550-6551. doi: 10.1021/ja0604717
7. [7]
  ZHENG N, STUCKY G D. A general synthetic strategy for oxide-supported metal nanoparticle catalysts[J]. J Am Chem Soc, 2006,128(44):14278-14280. doi: 10.1021/ja0659929
8. [8]
  TUZOSKAYA I, BOGDANCHIKOVA N, SIMAKOV A, JURIN V, PESTRYAKOV A, AVALOS M, FARIAS M H. Structure and electronic states of gold species in mordenites[J]. Chem Phys, 2007,338(1):23-32. doi: 10.1016/j.chemphys.2007.07.026
9. [9]
  PESTRYAKOV A, TUZOSKAYA I, SMOLENTSEVA E, BOGDANCHIKOVA N, JENTOFT F, KNOP-GERICKE A. Formation of gold nanoparticles in zeolites[J]. Int J Mod Phys B, 2005,19(15/17):2321-2326.
10. [10]
  WANG Z, XIE Y, LEIU C. Synthesis and characterization of noble metal (Pd, Pt, Au, Ag) nanostructured materials confined in the channels of mesoporous SBA-15[J]. J Phy Chem C, 2008,112(50):19818-19824. doi: 10.1021/jp805538j
11. [11]
  LI Y, JANG B W L. Non-thermal RF plasma effects on surface properties of Pd/TiO₂ catalysts for selective hydrogenation of acetylene[J]. Appl Catal A:Gen, 2011,392(1/2):173-179.
12. [12]
  LIU X Y, MOU C Y, LEE S, LI Y N, SECREST J, JANG B W L. Room temperature O₂ plasma treatment of SiO₂ supported Au catalysts for selective hydrogenation of acetylene in the presence of large excess of ethylene[J]. J Catal, 2012,285(1):152-159. doi: 10.1016/j.jcat.2011.09.025
13. [13]
  SOBCZAK I, RYDZ M, ZIOLEK M. The effect of alkali metal on the surface properties of potassium doped Au-Beta zeolites[J]. Mater Res Bull, 2013,48(2):795-801. doi: 10.1016/j.materresbull.2012.11.063
14. [14]
  QIN Ming-lei. Prepration of metal phosphides by hydrogen plasma reduction and their catalytic performance in hydrodesulfurization. Dalian:Dalian University of Technology, 2011.
15. [15]
  XIE Ke-chang, LI Zhong. Methanol and its Ramifications[M]. Beijing:Chemical Industry Press, 2002.
