Citation: LIU Hao-ran, LI Xiu-ping, ZHAO Rong-xiang, LI Ping. Preparation of H₂WO₄/GO and its ultrasonic-oxidative desulfurization in model oil[J]. Journal of Fuel Chemistry and Technology, ;2019, 47(7): 843-851. shu

Preparation of H₂WO₄/GO and its ultrasonic-oxidative desulfurization in model oil

1.
College of Petrochemical Engineering, College of Chemistry, Chemical Engineering, and Environmental Engineering, Liaoning Shihua University, Fushun 113001, China
2.
College of Chemistry & Material Science Engineering, College of Chemistry, Chemical Engineering, and Environmental Engineering, Liaoning Shihua University, Fushun 113001, China
3.
College of Environmental Science & Engineering, College of Chemistry, Chemical Engineering, and Environmental Engineering, Liaoning Shihua University, Fushun 113001, China

Corresponding author: ZHAO Rong-xiang, zylhzrx@126.com
Received Date: 31 January 2019
Revised Date: 10 May 2019

Fund Project: The project was supported by Doctoral Fund of Liaoning Province(201501105)Doctoral Fund of Liaoning Province 201501105

Figures(14)

H₂WO₄/GO was prepared by dipping method using tungstic acid and graphene oxide as raw materials. The morphology and structure of H₂WO₄/GO were characterized by XRD, FT-IR, SEM and BET. The ultrasonic-oxidation desulfurization of model oil containing DBT was carried out with H₂WO₄/GO as catalyst, H₂O₂ as oxidant agent and acetonitrile as extractant. Under the optimum conditions with 5 mL of model oil, 30% of tungstic acid loading(mass ratio), 0.02 g of catalyst, 1 mL of acetonitrile, H₂O₂/S mol ratio of 8, ultrasonic power of 150 W and at 50℃, the removal rate of DBT, 4, 6-DMDBT and BT can reach 96.6%, 81.2%, 72.8%, respectively. Besides, the recycling use of catalyst and the mechanism of ultrasonic-oxidation desulfurization were investigated.
- tungstic acid,
- graphene oxide,
- ultrasound,
- oxidative desulfurization,
- dibenzothiophene
