Application of regenerated cellulose and reduced graphene oxide film in synergistic power generation from moisture electricity generation and Mg-air batteries

Lisha LEI ^{1, #} ,
Wei YONG ^{1, #} ,
Yiting CHENG ¹ ,
Yibo WANG ¹ ,
Wenchao HUANG ¹ ,
Junhuan ZHAO ² ,
Zhongjie ZHAI ² ,
Yangbin DING ^{1, 2, 3,,}

1.
Huzhou Key Laboratory of Environmental Functional Materials and Pollution Control, Huzhou University, Huzhou, Zhejiang 313000, China
2.
Zhejiang Ruigao High tech Materials Co., Ltd., Huzhou, Zhejiang 313000, China
3.
Northeast Petroleum University, Daqing, Heilongjiang 163318, China

Corresponding author: Yangbin DING, 02566@zjhu.edu.cn
Received Date: 30 May 2024
Revised Date: 11 April 2025

Figures(9)

A green composite film (RCe_wp/rGO) made from regenerated waste paper cellulose (RCe_wp) and reduced graphene oxide (rGO) was designed and used as an active material. The film produced from recycled paper demonstrated a stable maximum peak current of 10 μA over a 7 000 s cycle, with a maximum output power of 2.34 μW·cm^-2 at a 100 Ω load. Additionally, the research highlighted the significant impact of metallic current collectors on moisture electricity generation. Notably, stainless steel collectors can produce an open-circuit voltage of up to 53 mV at 70% relative humidity (RH), as the redox reactions at the collector enhance current and voltage output under humid conditions. Furthermore, this moisture electricity generation film exhibited excellent performance when combined with magnesium-air batteries: at a 50% of RH, the RCe_wp/rGO electrode could generate an open-circuit voltage (V_oc) of up to 1.37 V and a short-circuit current density of 0.132 mA·cm^-2. When the RH increased to 90%, the V_oc further rose to 1.57 V, with a short-circuit current density of 64.2 mA·cm^-2. In contrast, the Mg-filter paper-Ni electrode, which was not connected to the moisture electricity generation film, only produced an output power and short-circuit current of 3.76×10^-4 mW and 0.306 μA·cm^-2, respectively.
