Citation: MA Kai, LIN Ning. Three-Dimensional Porous Carbon Prepared by Molten Salt Zinc-Thermal Method as Anode for High Performance Potassium Ion Batteries[J]. Chinese Journal of Inorganic Chemistry, ;2020, 36(3): 415-420. doi: 10.11862/CJIC.2020.058 shu

Three-Dimensional Porous Carbon Prepared by Molten Salt Zinc-Thermal Method as Anode for High Performance Potassium Ion Batteries

MA Kai ,
LIN Ning ^,

School of Chemistry and Materials Science, University of Science and Technology of China, Hefei 230026, China

Corresponding author: LIN Ning, ningl@mail.ustc.edu.cn
Received Date: 1 July 2019
Revised Date: 24 September 2019

Figures(4)

Three-dimensional (3D) porous carbon materials are successfully prepared by molten salt zinc-thermal method using sucrose as precursor and used as anode materials for potassium ion batteries. The prepared 3D porous carbon has a large number of interconnected channels, which can effectively alleviate the volume effect of the electrode during the charge-discharge cycling process, improve the infiltration of electrolyte to the electrode, shorten the diffusion path of K⁺. Therefore, it shows excellent cycle stability and rate performance. 3D porous carbon electrode delivers the specific capacity of 174.6 mAh·g^-1 after 2 500 cycles at current density of 0.5 A·g^-1 and 170 mAh·g^-1 at a high rate of 4.4 A·g^-1.
- zinc-thermal,
- 3D porous carbon,
- rate performance,
- cycle stability,
- potassium ion batteries
1. [1]
  Wu X, Leonard D P, Ji X. Chem. Mater., 2017, 29(12):5031- 5042 doi: 10.1021/acs.chemmater.7b01764
2. [2]
  Bie X, Kubota K, Hosaka T, et al. J. Mater. Chem. A, 2017, 5(9):4325-4330 doi: 10.1039/C7TA00220C
3. [3]
  Komaba S, Hasegawa T, Dahbi M, et al. Electrochem. Commun., 2015, 60:172-175 doi: 10.1016/j.elecom.2015.09.002
4. [4]
  Li H, Wang Z, Chen L, et al.Adv.Mater., 2009, 21(45):4593- 4607 doi: 10.1002/adma.200901710
5. [5]
  Nagaura T, Tozawa K. Progress in Batteries & Solar Cells. Brunswick: JEC Press, 1990:209
6. [6]
  Nishi Y.. Chem. Rec., 2001, 1(5):406-413 doi: 10.1002/tcr.1024
7. [7]
  Li T, Lin N, Han Y, et al. ACS Appl. Mater. Interfaces, 2018, 10(49):42469-42474 doi: 10.1021/acsami.8b16481
8. [8]
  Yi Z, Qian Y, Tian J, et al. J. Mater. Chem. A, 2019, 7(19): 12283-12291 doi: 10.1039/C9TA02204J
9. [9]
  Jian Z, Luo W, Ji X.. J. Am. Chem. Soc., 2015, 137(36):11566- 11569 doi: 10.1021/jacs.5b06809
10. [10]
  Yan K, Lu Z, Lee H W, et al. Nat. Energy, 2016, 1(3):16010 doi: 10.1038/nenergy.2016.10
11. [11]
  Luo W, Wan J, Ozdemir B, et al. Nano Lett., 2015, 15(11): 7671-7677 doi: 10.1021/acs.nanolett.5b03667
12. [12]
  Xing Z, Qi Y, Jian Z, et al. ACS Appl. Mater. Interfaces, 2016, 9(5):4343-4351
13. [13]
  Jian Z, Hwang S, Li Z, et al. Adv. Funct. Mater., 2017, 27 (26):1700324 doi: 10.1002/adfm.201700324
14. [14]
  Yi Z, Wang W, Qian Y, et al. ACS Sustainable Chem. Eng., 2018, 6(11):14230-14238 doi: 10.1021/acssuschemeng.8b02880
15. [15]
  Li Y, Jiang S, Qian Y, et al. Chem. Commun., 2019, 55(47): 6751-6754 doi: 10.1039/C9CC02971K
16. [16]
  Li W H, Ning Q L, Xi X T, et al. Adv. Mater., 2019, 31(4): 1804766 doi: 10.1002/adma.201804766
17. [17]
  Wang Y Y, Hou B H, Ning Q L, et al. Nanotechnology, 2019, 30(21):214002 doi: 10.1088/1361-6528/ab043a
18. [18]
  Wang P, Ye H, Yin Y X, et al. Adv. Mater., 2019, 31(4): 1805134 doi: 10.1002/adma.201805134
19. [19]
  Xiong P, Zhao X, Xu Y.. ChemSusChem, 2018, 11(1):202-208 doi: 10.1002/cssc.201701759
20. [20]
  Liu D, Huang X, Qu D, et al. Nano Energy, 2018, 52:1-10 doi: 10.1016/j.nanoen.2018.07.023
21. [21]
  Chen C, Wang Z, Zhang B, et al. Energy Storage Mater., 2017, 8:161-168 doi: 10.1016/j.ensm.2017.05.010
22. [22]
  Wang J, Polleux J, Lim J, et al. J. Phys. Chem. C, 2007, 111 (40):14925-14931 doi: 10.1021/jp074464w
23. [23]
  Conway B E, Birss V, Wojtowicz J. J. Power Sources, 1997, 66(1/2):1-14
24. [24]
  Li P, Hwang J Y, Park S M, et al. J. Mater. Chem. A, 2018, 6(26):12551-12558 doi: 10.1039/C8TA03340D
