Citation: CAI Hong, WU Guang-Wei, LAI Jia-Li, CHEN Jin-Ping, CHEN Yan-Fei, LI Dan. Selective Adsorption of CO₂ by Biological Metal-Organic Framework ZnBTCA[J]. Chinese Journal of Inorganic Chemistry, ;2019, 35(11): 2083-2088. doi: 10.11862/CJIC.2019.236 shu

Selective Adsorption of CO₂ by Biological Metal-Organic Framework ZnBTCA

CAI Hong ^1,, ,
WU Guang-Wei ¹ ,
LAI Jia-Li ¹ ,
CHEN Jin-Ping ¹ ,
CHEN Yan-Fei ¹ ,
LI Dan ^2,,

1.
School of Chemistry and Environmental Engineering, Hanshan Normal University, Chaozhou, Guangdong 521041, China
2.
College of Chemistry and Materials Science, Jinan University, Guangzhou 510632, China

Corresponding author: CAI Hong, tiddychen@163.com LI Dan, danli@jnu.edu.cn
Received Date: 12 September 2019
Revised Date: 27 September 2019

Figures(3)

A biological metal-organic framework (BioMOF) ZnBTCA was prepared by the solvent-thermal method, which showed interesting host-guest chemistry in CO₂ gas adsorption process. It was found that the adsorption enthalpy of CO₂ increased with the increase of adsorption capacity. Using four models to fit the adsorption isotherm of CO₂, we modeled and predicted the binary mixture selectivity by the ideal adsorbed solution theory (IAST), and tried to find a reasonable explanation for the abnormal adsorption behavior of ZnBTCA. ZnBTCA has high adsorption selectivity for CO₂ in CO₂/N₂ and CO₂/CH₄ binary systems due to the molecular sieve effect. This is attributed to the fact that ZnBTCA has NH₂, N-active site, and a large number of guest cations in the pores. The counterbalancing (CH₃)₂NH₂⁺ could not be evacuated through thermal activation, and the accessible micropore volume was reduced as a result.
- metal-organic framework,
- host-guest chemistry,
- gas absorption,
- molecular sieve effect
1. [1]
  Luo Y H, Dong L Z, Liu J, et al. Coord. Chem. Rev., 2019, 390:86-126 doi: 10.1016/j.ccr.2019.03.019
2. [2]
  Ding M, Flaig R W, Jiang H L, et al. Chem. Soc. Rev., 2019, 48:2783-2828 doi: 10.1039/C8CS00829A
3. [3]
  Lin R B, Xiang S, Xing H, et al. Coord. Chem. Rev., 2019, 378:87-103 doi: 10.1016/j.ccr.2017.09.027
4. [4]
  Addicoat M, Bennett T, Chapman K, et al. Faraday Discuss., 2017, 201:175-194 doi: 10.1039/C7FD90044A
5. [5]
  Liao P Q, Zhou D D, Zhu A X, et al. J. Am. Chem. Soc., 2012, 134:17380-17383 doi: 10.1021/ja3073512
6. [6]
  Li T, Chen D L, Sullivan J E, et al. Chem. Sci., 2013, 4:1746-1755 doi: 10.1039/c3sc22207a
7. [7]
  Nugent P, Belmabkhout Y, Burd S D, et al. Nature, 2013, 495:80-84 doi: 10.1038/nature11893
8. [8]
  Emerson A J, Chahine A, Batten S R, et al. Coord. Chem. Rev., 2018, 365:1-22 doi: 10.1016/j.ccr.2018.02.012
9. [9]
  Li J R, Ma Y, McCarthy M C. Coord. Chem. Rev., 2011, 255:1791-1823 doi: 10.1016/j.ccr.2011.02.012
10. [10]
  Li H, Wang K, Sun Y, et al. Mater. Today, 2018, 21:108-121 doi: 10.1016/j.mattod.2017.07.006
11. [11]
  Lin R B, Xiang S, Li B, et al. Coord. Chem. Rev., 2019, 384:21-36 doi: 10.1016/j.ccr.2019.01.009
12. [12]
  Cai H, Huang Y L, Li D. Coord. Chem. Rev., 2019, 378:207-221 doi: 10.1016/j.ccr.2017.12.003
13. [13]
  Cai H, Lu W, Yang C, et al. Adv. Opt. Mater., 2019, 7:1801149 doi: 10.1002/adom.201801149
14. [14]
  CAI Hong, XU Li-Li, LI Mian, et al. Chin. Sci. Bull., 2016, 16:1762-1773
15. [15]
  Cai H, Li M, Lin X R, et al. Angew. Chem. Int. Ed., 2015, 54:10454-10459 doi: 10.1002/anie.201502045
16. [16]
  Sumida K, Rogow D L, Mason J A, et al. Chem. Rev., 2012, 112:724-781 doi: 10.1021/cr2003272
17. [17]
  Cessford N F, Seaton N A, Düren T. Ind. Eng. Chem. Res., 2012, 51:4911 doi: 10.1021/ie202219w
18. [18]
  Li R J, Li M, Zhou X P, et al. Chem. Commun., 2014, 50:4047-4049 doi: 10.1039/C3CC49684H
19. [19]
  Li R J, Li M, Zhou X P, et al. CrystEngComm, 2014, 16:6291-6295 doi: 10.1039/C4CE00279B
20. [20]
  Li J R, Kuppler R J, Zhou H C. Chem. Soc. Rev., 2009, 38:1477-1504 doi: 10.1039/b802426j
