Citation: LI Ling, WANG Dong-Yang, ZHANG Xue, WANG Qi-Ming, FU LI-Shan, Yu Min-Si, XIAO Jin-Chong, ZHAO Xiao-Hui. Film Thickness of Transition Metal MoS₂/CNFs Electrode Effect on Dye-Sensitized Solar Cell[J]. Chinese Journal of Inorganic Chemistry, ;2018, 34(11): 2019-2024. doi: 10.11862/CJIC.2018.264 shu

Film Thickness of Transition Metal MoS₂/CNFs Electrode Effect on Dye-Sensitized Solar Cell

1.
Hebei Key Lab of Optic-electronic Information and Materials, College of Physics Science and Technology, Hebei University, Baoding, Hebei 071002, China
2.
College of Chemistry and Environmental Science, Hebei University, Baoding, Hebei 071002, China

Corresponding author: ZHAO Xiao-Hui, xhzhao@hbu.edu.cn
Received Date: 28 June 2018
Revised Date: 11 September 2018

Figures(6)

Two-dimensional layered molybdenum sulfide supported on carbon nanofibers (MoS₂/CNFs) were successfully obtained by electro-spinning and hydrothermal methods and showed excellent electrochemical properties. During the preparation of DSSCs, the film thickness of the electrode had a great influence on the performance of the DSSCs. Focuses on the effect of the film thickness of the counter electrode prepared by spraying method on the optical properties of the DSSCs and the optimum counter electrode film thickness was obtained. The experimental results show that the film thickness of the MoS₂/CNFs composite counter electrode material was 8 μm, the photoelectric conversion efficiency of the battery reached a maximum value of 7.78%.
- transition metal MoS₂,
- electrochemical characteristics,
- dye sensitized solar cell,
- counter electrode
1. [1]
  Oregan B, Gratzel M. Nature, 1991, 353(6346):737-740 doi: 10.1038/353737a0
2. [2]
  Mathew S, Yella A, Gao P, et al. Nat. Chem., 2014, 6(3):242-247 doi: 10.1038/nchem.1861
3. [3]
  Freitag M, Teuscher J, Saygili Y, et al. Nat. Photonics, 2017, 11(6):372-378 doi: 10.1038/nphoton.2017.60
4. [4]
  Ma T, Fang X, Akiyama M, et al. J. Electroanal. Chem., 2004, 574(1):77-83 doi: 10.1016/j.jelechem.2004.08.002
5. [5]
  Fang X M, Ma T L, Guan G Q, et al. J. Electroanal. Chem., 2004, 570(2):257-263 doi: 10.1016/j.jelechem.2004.04.004
6. [6]
  Novoselov K S, Geim A K, Morozov S V, et al. Science, 2004, 306(5696):666-669 doi: 10.1126/science.1102896
7. [7]
  Mattheiss L F. Phys. Rev. B:Condens. Matter, 1973, 8(8):3719-3740 doi: 10.1103/PhysRevB.8.3719
8. [8]
  Wilson J A, Yoffe A D. Adv. Phys., 1969, 18(73):193-335 doi: 10.1080/00018736900101307
9. [9]
  ZHOU Sha-Sha, CHEN Jun-Nian, GAN Lin, et al. Chin. Sci. Bull., 2016, 61(8):912
10. [10]
  Chang K, Chen W. Chem. Commun., 2011, 47(14):4252-4254 doi: 10.1039/c1cc10631g
11. [11]
  Wang M, Anghel A M, Marsan B, et al. J. Am. Chem. Soc., 2009, 131(44):15976-15977 doi: 10.1021/ja905970y
12. [12]
  Kavan L, Yum J H, Nazeeruddin M K, et al. ACS Nano, 2011, 5(11):9171-9178 doi: 10.1021/nn203416d
13. [13]
  Wu M X, Wang Y D, Lin X, et al. J. Mater. Chem., 2013, 1(34):9672-9679 doi: 10.1039/c3ta12077e
14. [14]
  Roy-Mayhew J D, Bozym D J, Punckt C, et al. ACS Nano, 2010, 4(10):6203-6211 doi: 10.1021/nn1016428
15. [15]
  ZHAO Xiao-Chong, LIN Hong, YANG Pan, et al. Rare Metal Materials and Engineering, 2011, 40(1):335-338
16. [16]
  Hauch A, Georg A. Electrochim. Acta, 2001, 40(22):3457-3466
17. [17]
  Ferrari A C, Robertson J. Phys. Rev. B:Condens. Matter, 2000, 61(20):14095-14107 doi: 10.1103/PhysRevB.61.14095
