Citation: GUO Cai-Hong, LI Hai-Yu, LI Jun, JIA Jian-Feng, WU Hai-Shun. Theoretical Study on Structure and Property of Iron Carbonyl Derivatives Fe (CO)_5-x(PR₃)_x[J]. Chinese Journal of Inorganic Chemistry, ;2017, 33(7): 1187-1195. doi: 10.11862/CJIC.2017.143 shu

Theoretical Study on Structure and Property of Iron Carbonyl Derivatives Fe (CO)_5-x(PR₃)_x

School of Chemical and Material Science, Shanxi Normal University, Key Laboratory of Magnetic Molecules & Magnetic Information Materials Ministry of Education, Linfen, Shanxi 041004, China

Corresponding author: GUO Cai-Hong, sxgch2006@163.com
Received Date: 31 December 2016
Revised Date: 9 May 2017

Figures(4)

The geometric structures, electronic configurations, bonding characteristic, and thermodynamic properties of low valence iron complexes Fe (CO)_5-x(PR₃)_x(x=1~3, R=H, F, Me) were studied using the density functional theory (DFT) method.The results show that the geometric framework of Fe (CO)_5-x(PR₃)_x is not aberrant but maintain the distorted trigonal bipyramidal structure after the introduction of phosphorus ligand.Natural bond orbital (NBO) analysis show that there is charge transfer between the phosphorus ligand to the carbonyl iron fragment.Moreover, the covalent interaction between Fe and CO is enhanced.The phosphorus ligand dissociation energy is lower than the first carbonyl dissociation energy from the most stable structure Fe (CO)_5-x(PR₃)_x.This indicates that the reactivity of Fe (CO)_5-x(PR₃)_x is largely greater than Fe (CO)₅.
- density functional theory,
- iron carbonyl derivatives,
- phosphorus ligand,
- dissociation energy,
- natural bond orbital (NBO) analysis
1. [1]
  Zhou L Q, Li G L, Li Q S, et al. Inorg. Chem., 2011, 50(24): 12531-12538 doi: 10.1021/ic201490m
2. [2]
  Lengyl J, Kocisek J, Farník M, et al. J. Phys. Chem. C, 2016, 120(13):7397-7402 doi: 10.1021/acs.jpcc.6b00901
3. [3]
  Aiswaryalakshmi P, Mani D, Arunan E. Inorg. Chem., 2013, 52(15):9153-9161 doi: 10.1021/ic4015114
4. [4]
  Anne K, Hickey, Lee W T, et al. Organometallics, 2016, 35 (17):3069-3073 doi: 10.1021/acs.organomet.6b00599
5. [5]
  Anne K, Hickey, Chen C H, et al. Organometallics, 2015, 34 (18):4560-4566 doi: 10.1021/acs.organomet.5b00646
6. [6]
  YU Long, LÜ Zhi-Feng, SONG Cheng-Li, et al. J. Mol. Catal.(China), 2012, 26(3): 284-291
7. [7]
  LIU Rui, XIONG Xu-Mao, MU Xin-Yuan, et al. J. Mol. Catal.(China), 2015, 29(2): 97-102
8. [8]
  Monda L, Quincke F. J. Chem. Soc., 1891, 59:604-607 doi: 10.1039/CT8915900604
9. [9]
  Mitchener J, Wrighton M. J. Am. Chem. Soc., 1981, 103(4): 975-977 doi: 10.1021/ja00394a060
10. [10]
  Schroeder M A, Wrighton M. J. Am. Chem. Soc., 1976, 98 (2):551-558 doi: 10.1021/ja00418a039
11. [11]
  Marciniec B. Silicon Chem., 2002, 1(3):155-174 doi: 10.1023/A:1021235922742
12. [12]
  Kakiuchi F, Tanaka Y, Chatani N, et al. J. Organomet. Chem., 1993, 456(1):45-47 doi: 10.1016/0022-328X(93)83315-M
13. [13]
  Howell J, Palin M, McArdle P, et al. Inorg. Chem., 1993, 32 (16):3493-3500 doi: 10.1021/ic00068a019
14. [14]
  Zampella G, Fantucci P, Gioia L D. J. Am. Chem. Soc., 2009, 131(31):10909-10917 doi: 10.1021/ja902727z
15. [15]
  Clark R J. Inorg. Chem., 1964, 3(10):1395-1398 doi: 10.1021/ic50020a011
16. [16]
  Bramley R, Figgis B N, Nyholm R S. Trans. Faraday Soc., 1962, 58:1893-1896 doi: 10.1039/tf9625801893
17. [17]
  Muetterties E L, Mahler W, Schmutzler R. Inorg. Chem., 1963, 2(3):613-618 doi: 10.1021/ic50007a047
18. [18]
  Berry R S. J. Chem. Phys., 1960, 32(3):933-938 doi: 10.1063/1.1730820
19. [19]
  Haas H, Sheline R K. J. Chem. Phys., 1967, 47(8):2996-3021 doi: 10.1063/1.1712327
20. [20]
  Mahnke H, Clark R J, Rosanske R, et al. J. Chem. Phys., 1974, 60(8):2997-3004 doi: 10.1063/1.1681481
21. [21]
  Mahnke H, Clark R J, Sheline R K, et al. J. Chem. Phys., 1977, 66(11):4822-4826 doi: 10.1063/1.433819
22. [22]
  Nathanson G, Gitlin B, Rosan A M, et al. J. Chem. Phys., 1981, 74(1):361-369 doi: 10.1063/1.440841
23. [23]
  Therien M J, Ni C L, Anson F C, et al. J. Am. Chem. Soc., 1986, 108(14):4037-4042 doi: 10.1021/ja00274a031
24. [24]
  Keiter R L, Keiter E A, Hecker K H, et al. Organometallics, 1988, 7(12):2466-2469 doi: 10.1021/om00102a006
25. [25]
  Allcock H, Therient M, Trogler W, et al. Inorg. Synth., 1989, 25:151-156 doi: 10.1002/SERIES2146
26. [26]
  Brunet J J, Commenges G, Kindela F B, et al. Organometallics, 1992, 11(3):1343-1350 doi: 10.1021/om00039a045
27. [27]
  Nayak S K, Burkey T J. J. Am. Chem. Soc., 1993, 115(14): 6391-6397 doi: 10.1021/ja00067a064
28. [28]
  Frenking G, Wichmann K, Golla W, et al. Organometallics, 2002, 21(14):2921-2930 doi: 10.1021/om020311d
29. [29]
  Frisch M, Trucks G, Schlegel H, et al. Gaussian 09, Revision C.01, Gaussian, Inc., Wallingford CT, 2010.
30. [30]
  Wu H S, Guo C H, Jia J, et al. ChemPhysChem, 2013, 14 (17):3902-3905 doi: 10.1002/cphc.v14.17
31. [31]
  Bielinski E A, Förster M, Zhang Y, et al. ACS Catal., 2015, 5(4): 2404-2415 doi: 10.1021/acscatal.5b00137
32. [32]
  Zhang Z, Li Q S, Xie Y M, et al. Inorg. Chem., 2009, 48(5): 1974-1988 doi: 10.1021/ic8016276
33. [33]
  Reed A E, Weinstock R B, Weinhold F. J. Chem. Phys., 1985, 83(2):735-746 doi: 10.1063/1.449486
34. [34]
  TIAN Zhen-Ning, XU Xuan. Acta Phys. -Chim. Sin., 2008, 24(8):1481-1486
35. [35]
  Wang W, Weitz E. J. Phys. Chem. A, 1997, 101(12):2358 -2363 doi: 10.1021/jp964090z
36. [36]
  Gonzalez-Blanco O, Branchadell V. J. Chem. Phys., 1999, 110(2):778-783 doi: 10.1063/1.478045
37. [37]
  Angelici R J, Siefert E E. J. Organomet. Chem., 1967, 8(2): 374-376 doi: 10.1016/S0022-328X(00)91055-6
38. [38]
  Lewis K E, Golden D M, Smith G P. J. Am. Chem. Soc., 1984, 106(14):3905-3912 doi: 10.1021/ja00326a004
39. [39]
  Radius U, Bickelhaupt F M, Ehlers A W, et al. Inorg. Chem., 1998, 37(5):1080-1090 doi: 10.1021/ic970897+
40. [40]
  Goumans T, Andreas W, Marc C, et al. J. Am. Chem. Soc., 2003, 125(12):3558-3567 doi: 10.1021/ja029135q
