Citation: SUN Wei-Yi, LI Pan, TAO Zhan-Liang, CHEN Jun. Size-Controlled MoS₂ Nanodots for Luminescent Property[J]. Chinese Journal of Inorganic Chemistry, ;2017, 33(5): 796-800. doi: 10.11862/CJIC.2017.111 shu

Size-Controlled MoS₂ Nanodots for Luminescent Property

Key Laboratory of Advanced Energy Materials Chemistry (Ministry of Education), College of Chemistry, Nankai University; Collaborative Innovation Center of Chemical Science and Engineering, Tianjin 300071, China

Corresponding author: TAO Zhan-Liang, taozhl@nankai.edu.cn
Received Date: 23 December 2016
Revised Date: 6 March 2017

Figures(4)

Molybdenum disulfide, which is composed of a monolayer or few layers, is a new kind of two-dimensional materials following the study of grapheme. It is a kind of direct band-gap semiconductor with excellent photoelectric properties, which has attracted much attention. In this paper, molybdenum disulfide with different particle size was successfully prepared by heat-up method. The MoCl₅ was reacted with L-cysteine in the presence of oleylamine at 220℃, and we performed different reaction time from 1 to 5 h to understand the formation mechanism. There are two mechanisms occurred in the formation process of MoS₂ nanodots:one is the Ostwald ripening and the other is an epitaxial growth. Until there are no enough nuclei for growth, the size remains unchanged regardless of the growth of the time. The prepared MoS₂ nanodots are homogeneous in the aspects of size and height from the large range due to the protection of OLA. In addition, OLA providing a strong reductive environment reduces Mo⁵⁺ to Mo⁴⁺ and avoids oxidation of the nanoparticles, which integrated with L-cysteine to results in the formation of H₂S. The molybdenum disulfide quantum dots prepared for 3 h had monolayer structure. We also investigate the photoluminescence behaviors of the materials to inquire the size effect. The fluorescence spectra and Raman spectra of three kinds of molybdenum disulfides were studied. It was found that when the particle size or the excitation wavelength increased, the peak position of the fluorescence spectrum occurred red shift.
- molybdenum disulfide,
- nanodots,
- heat-up method,
- luminescent,
- size effect
1. [1]
  Novoselovl K S, Geiml A K, Morozov S V, et al. Science, 2004, 306(5696):666-669 doi: 10.1126/science.1102896
2. [2]
  Wang Q H, Kalantar-Zadeh K, Kis A, et al. Nat. Nanotechnol., 2012, 7:699-712 doi: 10.1038/nnano.2012.193
3. [3]
  Splendiani A, Sun L, Zhang Y, et al. Nano Lett., 2010, 10(4):1271-1275 doi: 10.1021/nl903868w
4. [4]
  SHEN Cheng, ZHANG Qing, SHI Dong, et al. Acta Chim. Sinica, 2015, 73:954-958
5. [5]
  Mak K F, He K L, Shan J, et al. Phys. Rev. Lett., 2010, 105:136805 doi: 10.1103/PhysRevLett.105.136805
6. [6]
  Cesano F, Bertarione S, Piovano A, et al. Catal. Sci., Technol., 2011, 1:123-126 doi: 10.1039/c0cy00050g
7. [7]
  Perkins F K, Friedman A L, Cobas E, et al. Nano Lett., 2013, 13(2):668-673 doi: 10.1021/nl3043079
8. [8]
  Chen W, Santos E J G, Zhu W G, et al. Nano Lett., 2013, 13(2):509-514 doi: 10.1021/nl303909f
9. [9]
  Gopalakrishnan D, Damien D, Shaijumon M M. ACS Nano, 2014, 8(5):5297-5303 doi: 10.1021/nn501479e
10. [10]
  Ren X, Pang L, Zhang Y, et al. J. Mater. Chem. A, 2015, 3:10693-10697 doi: 10.1039/C5TA02198G
11. [11]
  WANG Li-Xiu, WEI Lin, TAO Zhan-Liang, et al. Chinese J. Inorg. Chem., 2014, 30(9):2043-2048
12. [12]
  Chang K, Chen W. J. Mater. Chem., 2011, 21:17175-17184 doi: 10.1039/c1jm12942b
13. [13]
  Xie J F, Zhang J J, Li S, et al. J. Am. Chem. Soc., 2013, 135(47):17881-17888 doi: 10.1021/ja408329q
14. [14]
  Buscema M, Steele G A, Van der Zant H S J. Nano Res., 2014, 7(4):561-571 doi: 10.1007/s12274-014-0424-0
15. [15]
  Splendiani A, Sun L, Zhang Y, et al. Nano Lett., 2010, 10(4):1271-1275 doi: 10.1021/nl903868w
16. [16]
  Ma C B, Qi X, Chen B, et al. Nanoscale, 2014, 6:5624-5629 doi: 10.1039/c3nr04975b
17. [17]
  Liu Y T, Zhu X D, Duan Z Q, et al. Chem. Commun., 2013, 49:10305-10307 doi: 10.1039/c3cc45936e
18. [18]
  Kwon S G, Hyeon T. Small, 2011, 7(19):2685-2702 doi: 10.1002/smll.v7.19
19. [19]
  GU Ping-Chao, ZHANG Kai-Liang, FENG Yu-Lin, et al. Acta Phys. Sin., 2016, 65(1):018102
20. [20]
  Mak K F, Lee C, Hone J, et al. Phys. Rev. Lett., 2010, 105:136805 doi: 10.1103/PhysRevLett.105.136805
21. [21]
  Gopalakrishnan D, Damien D, Li B, et al. Chem. Commun., 2015, 51:6293-6296 doi: 10.1039/C4CC09826A
22. [22]
  Stengl V, Henych J. Nanoscale, 2013, 5:3387-3394 doi: 10.1039/c3nr00192j
23. [23]
  Lin H, Wang C, Wu J, et al. New J. Chem., 2015, 39:8492-8497 doi: 10.1039/C5NJ01698C
